The Siemens 6AG1132-4BF00-7AA0 is an 8-channel digital output module for the SIPLUS S7-1200 family, rated for 0.5 A per output and 4 A total across the module. Transistor outputs with short-circuit and reverse polarity protection keep fault-induced downtime low in automated lines. The temperature range spans -40 to 70 °C, covering most cleanroom subfloor and cabinet microclimates. No diagnostics function is built in, so fault detection relies on external monitoring or the connected load's feedback.
Integration & Performance
The module occupies a 15 mm slot, draws 10 mA from the backplane, dissipates 1.5 W, and offers switching speeds of 100 Hz resistive, 2 Hz inductive, and 10 Hz lamp loads. Cable length reaches 600 m unshielded; isolation tested at 500 V DC.
