Siemens 6AG1134-4FB01-2AB0 — PLCs (Programmable Logic Controllers)

Siemens 6AG1134-4FB01-2AB0 2AI U/I HF, 15 mm

MPN6AG1134-4FB01-2AB0

Siemens SIMATIC ET 200SP, Analog Input Module, 2 AI U/I HF, 6AG1134-4FB01-2AB0, 2 channels, voltage ±10 V, 15 mm, integrating conversion.

$1,456.11Ref. price · indicative, final on quote

Add to RFQ

Siemens 6AG1134-4FB01-2AB0 datasheet (PDF)

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6AG1134-4FB01-2AB0 — Electrical
Parameter	Value
Rated value (DC)	24 V; From power module
Power loss (typ.)	0.6 W

6AG1134-4FB01-2AB0 — Environmental
Parameter	Value
Installation altitude, max.	5 000 m
Temperature, min.	-25 °C; = Tmin
Temperature, max.	70 °C; = Tmax
Ambient temperature vs. altitude/pressure derating	Tmin ... Tmax at 1 140 hPa ... 795 hPa (-1 000 m ... +2 000 m) // Tmin ... (Tmax - 10 K) at 795 hPa ... 658 hPa (+2 000 m ... +3 500 m) // Tmin ... (Tmax -20 K) at 658 hPa ... 540 hPa (+3 500 m ... +5 000 m)

6AG1134-4FB01-2AB0 — Mechanical
Parameter	Value
Width	15 mm
Height	81 mm
Depth	52 mm
Weight (approx.)	40 g

Product details

The Siemens 6AG1134-4FB01-2AB0 is an analog input module for the SIMATIC ET 200SP distributed I/O system. It provides two analog inputs for voltage measurement, covering ranges up to ±10 V, with integrating conversion and programmable digital filtering in four stages. Isolation to 500 V DC between channels and backplane bus. Module width is 15 mm, matching the ET 200SP BaseUnit footprint. Power drawn from the backplane bus at 24 V DC, typical power loss 0.6 W. Conversion time per channel 65 ms (basic), cycle time scales with number of active channels. Shielded cable max. 200 m.
