The 6AG1134-4GB01-2AB0: Rated for -25 °C to 60 °C ambient, this module handles unheated cabinets or warm panels without derating. The 2-input count sets the BOM line for analog sensing; each input is individually parameterizable for wire-break detection (enabled by default). Selectable integration time of 16,7 ms or 20 ms provides line-cycle rejection. Digital filtering offers 1x, 4x, 32x, or 64x cycle times; basic conversion per channel is 65 ms. Group diagnostics and overflow/underflow alarms are enable/disable per channel group, and the module reports a group error (SF LED red) on any fault. Isochronous mode is not supported, so this is not the right part for time-synchronous applications. Reverse-polarity protection on each input limits destruction to 35 mA per channel. CE and UL approvals are present — sufficient for most industrial control panels but verify if your facility requires additional marks.
Siemens 6AG1134-4GB01-2AB0 SIPLUS S7-1200 Analog Input, 2 In
MPN6AG1134-4GB01-2AB0
Siemens SIPLUS S7-1200 analog input module, order code 6AG1134-4GB01-2AB0, 2 inputs 4–20 mA, temperature range -25…60 °C, 15 mm wide.
$227.33Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V; From power module |
| Power loss (typ.) | 0.6 W |
| Parameter | Value |
|---|---|
| Installation altitude, max. | 5 000 m |
| Temperature, min. | -25 °C; = Tmin |
| Temperature, max. | 60 °C; = Tmax |
| Ambient temperature vs. altitude/pressure derating | Tmin ... Tmax at 1 140 hPa ... 795 hPa (-1 000 m ... +2 000 m) // Tmin ... (Tmax - 10 K) at 795 hPa ... 658 hPa (+2 000 m ... +3 500 m) // Tmin ... (Tmax -20 K) at 658 hPa ... 540 hPa (+3 500 m ... +5 000 m) |
| Parameter | Value |
|---|---|
| Width | 15 mm |
| Height | 81 mm |
| Depth | 52 mm |
| Weight (approx.) | 40 g |
Product details
Frequently asked questions
What is the operating temperature range?
Rated for -25°C to 60°C ambient, covering most industrial indoor and unheated cabinet environments.
What compliance documentation is available?
CE and UL approvals are listed. Check with your compliance team for RoHS/REACH status; the evidence does not confirm those marks.
