Siemens 6AG1153-2BA02-7XB0

Siemens 6AG1153-2BA02-7XB0 PROFIBUS DP Module, 12 Mbit/s

MPN 6AG1153-2BA02-7XB0

Siemens SIMATIC DP, PROFIBUS DP interface module, 6AG1153-2BA02-7XB0, 12 Mbit/s, 0.466 ns time resolution, I2t 0.1 A²·s.

$443.48 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6AG1153-2BA02-7XB0 specifications
ParameterValue
Temp operating max20 °C
Temp operating min10 °C
Depth117 mm
Width40 mm
Height125 mm
Accuracy1 ms; 1 ms at up to 8 modules; 10 ms at up to 12 modules
Time formatRFC 1119

Product details

PROFIBUS DP interface with time-stamping

The Siemens 6AG1153-2BA02-7XB0 is a PROFIBUS DP slave interface module providing time stamping on signal change with 0.466 ns resolution, storing up to 15 message buffers each holding 20 events, and supporting automatic baud rate search up to 12 Mbit/s. Transmission protocol follows PROFIBUS DP to EN 50170, with a 9-pin sub-D connector. The module integrates into the backplane bus and draws a maximum of 600 mA from the 5 V DC supply. Potential separation is present; isolation tested at 500 V.

Key ratings and protection

The I2t rating of 0.1 A²·s defines the let-through energy that the module can withstand; coordinate upstream protection accordingly. Inrush current is typ. 3 A at cold restart. Power loss is typ. 5.5 W. The module's current consumption on the backplane bus (5 V DC) is 1.5 A max. Time stamping accuracy is 1 ms with up to 8 modules, degrading to 10 ms with up to 12 modules. Time format follows RFC 1119.

Configuration is supported in STEP 7, COM PROFIBUS, or via the GSD file SI04801.GSG for non-Siemens tools.

MPN
6AG1153-2BA02-7XB0
