Mounting and power
The 6AG1326-2BF41-2AB0: Housed in an 80 x 125 x 120 mm enclosure. Requires a 40-pin front connector. Draws up to 100 mA from the backplane bus at 5 V DC and 75 mA from the supply voltage at 24 V. Typical power loss 12 W.
Siemens 6AG1326-2BF41-2AB0 Fail-Safe DO Module, 8 Outputs, 2
MPN6AG1326-2BF41-2AB0
Siemens SIPLUS S7-1200 6AG1326-2BF41-2AB0 fail-safe digital output module, 8 outputs, 2 A rated, 24 V DC, -25 to 60 °C.
$1,268.73Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Digital outputs | 8 |
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V; 2L+, 3L+ |
| Power loss (typ.) | 12 W |
| Short-circuit protection | Yes |
| Parameter | Value |
|---|---|
| Installation altitude, max. | 2 000 m |
| Temperature, min. | -25 °C |
| Temperature, max. | 60 °C |
| Ambient temperature vs. altitude/pressure derating | Tmin ... Tmax at 1 140 hPa ... 795 hPa (-1 000 m ... +2 000 m) |
| Parameter | Value |
|---|---|
| Width | 80 mm |
| Height | 125 mm |
| Depth | 120 mm |
| Weight (approx.) | 465 g |
Product details
Frequently asked questions
What is the operating temperature range?
-25 °C minimum to 60 °C maximum. This covers extended ambient conditions typical for SIPLUS variants.
What connector does it require?
A 40-pin front connector is required to wire the outputs and power supply.
