Siemens 6AG1331-1KF02-4AB0 — Analog Input Modules

Siemens 6AG1331-1KF02-4AB0 SIPLUS SM 331 AI, 0-60°C

MPN6AG1331-1KF02-4AB0

Siemens 6AG1331-1KF02-4AB0 SIPLUS SM 331 analog input module, Pt100, Ni100, Ni1000, LG-Ni1000, resistance, 0-20 mA, 0-10 V, 1-5 V, 0 to 60 °C, 40 x 125 x 117 mm.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

6AG1331-1KF02-4AB0 — Inputs & Signal Ranges
ParameterValue
Number of analog inputs8
Current input rangeYes
Voltage input rangeYes
Resistance measuring rangesYes
RTD support (resistance thermometer)Yes
Thermocouple support (types)No
Input range: 0 to 20 mAYes
Input range: 4 to 20 mAYes
Input range: -10 to +10 VYes
Input range: -5 to +5 VYes
Input range: -80 to +80 mVNo
Input range: 0 to 600 OhmYes
RTD type: Pt100Yes; Standard/climate
RTD type: Pt200No
Current measurement: 2-wire transducerYes; with external supply
Current measurement: 4-wire transducerYes
Input resistance (0 to 20 mA)100 Ω
Input resistance (4 to 20 mA)100 Ω
Input resistance (-10 to +10 V)100 kΩ
Permissible input voltage, max. (destruction limit)30 V; 12 V continuous, 30 V for max. 1 s
Permissible input current, max. (destruction limit)40 mA
Max. shielded signal cable length200 m; max. 50 m at 50 mV
6AG1331-1KF02-4AB0 — Measurement Performance
ParameterValue
Resolution (bit incl. sign), max.13 bit
Voltage measurement error (±)0.4 %; 0.4% (±5 V, 10 V, 1 to 5 V, 0 to 10 V); 0.3% (±50 mV, 500 mV, 1 V)
Current measurement error (±)0.3 %; ±20 mA, 0 to 20 mA, 4 to 20 mA
Interference voltage suppression (at interference frequency)50 / 60 Hz
6AG1331-1KF02-4AB0 — Diagnostics & Monitoring
ParameterValue
Diagnostic alarmNo
Diagnostics functionNo
Limit value alarmNo
6AG1331-1KF02-4AB0 — Isolation
ParameterValue
Isolation: channels to backplane busYes
Isolation: between channelsNo
Isolation test voltage500 V DC
6AG1331-1KF02-4AB0 — Power
ParameterValue
Power loss, typ.0.4 W
6AG1331-1KF02-4AB0 — Mechanical
ParameterValue
Required front connector40-pin
Width40 mm
Height125 mm
Depth117 mm
Weight, approx.250 g

Product details

SIPLUS SM 331 AI Overview

The Siemens 6AG1331-1KF02-4AB0 is a SIPLUS analog input module for the S7-300 rack, rated for 0 to 60 °C ambient and carrying CE, FM, KC, and UL approvals. It reads resistance temperature sensors (Pt100, Ni100, Ni1000, LG-Ni1000) and analog signals (0-20 mA, 0-10 V, 1-5 V) across eight channels, fitting the 40 mm wide S7-300 footprint.

Temperature and Signal Ranges

Operating range spans 0 °C to 60 °C, wider than standard S7-300 AI modules; suited for unheated control cabinets or near-process heat. RTD support covers Pt100, Ni100, Ni1000 (standard/climate) and LG-Ni1000; no thermocouple types are supported. Voltage inputs include 0-10 V and 1-5 V; current inputs include 0-20 mA, plus a resistance measurement mode.

Certification and Mounting

CE, FM (CofC 3028431), KC, and UL (File E239877) marks simplify compliance for installations requiring North American or Korean approvals. The module occupies a 40 mm wide slot on the S7-300 mounting rail; depth is 117 mm including the backplane bus connector.

Frequently asked questions

What is the operating temperature range of 6AG1331-1KF02-4AB0?

The ambient temperature range is 0 °C to 60 °C, covering normal industrial enclosures and mild heat zones.

Which safety and product approvals does this module carry?

It holds CE, FM (CofC 3028431), KC, and UL (File E239877) certifications, suitable for global panel builds.
