Siemens 6ED1052-2CC00-0BA3 — PLCs (Programmable Logic Controllers)

Siemens 6ED1052-2CC00-0BA3 LOGO! 24O Logic Module, 8DI/4DO T

MPN6ED1052-2CC00-0BA3

Siemens LOGO! 24O logic module, 6ED1052-2CC00-0BA3, 24V DC, 8 DI (2 AI), 4 transistor DO, 0.3 A per output, 0-55 °C, 4TE, no display.

Siemens 6ED1052-2CC00-0BA3 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

6ED1052-2CC00-0BA3 — I/O
ParameterValue
Digital inputs8; of which 2 analog are usable
Digital outputs4; Transistor
6ED1052-2CC00-0BA3 — Environmental
ParameterValue
Temperature, min.0 °C
Temperature, max.55 °C
6ED1052-2CC00-0BA3 — Mechanical
ParameterValue
Width72 mm; 4TE
Height90 mm
Depth55 mm
6ED1052-2CC00-0BA3 — Electrical
ParameterValue
Short-circuit protectionYes; electrical (1 A)

Product details

The Siemens 6ED1052-2CC00-0BA3 is a LOGO! 24O logic module — a DIN-rail mounted micro PLC running at 24 V DC. It gives you 8 digital inputs (two of which are usable as analog inputs) and 4 transistor outputs rated for 0.3 A maximum each at signal '1'. Memory holds 56 function blocks, expandable with extra modules. Temperature range is 0 °C to 55 °C, and the unit is 72 mm wide (4TE), 90 mm high, 55 mm deep — fits standard 35 mm DIN rail.

This module carries CE, UL, CSA, FM, and Marine approvals, and is rated limit class B for residential environments.

Frequently asked questions

What are the key specifications?

8 digital inputs (2 analog-capable), 4 transistor outputs (0.3 A max each), 24 V DC supply, 0-55 °C operating range, 4TE wide, memory 56 blocks.

Can I drop this into a panel wired for the 6ED1052-1MD00-0BA6 without rewiring?

No. The -2CC00 uses transistor outputs (0.3 A) while the -1MD00 uses relays (10 A resistive). The input side is similar but the -2CC00 has fewer analog inputs (2 vs 4). Physical dimensions and mounting are identical, so the panel cut-out is fine, but output wiring must be changed.
