Siemens LOGO! 6ED1052-2CC08-0BA0, logic module without display, 24 V DC, 8 DI (4 AI), 4 DO transistor, 400 blocks, Ethernet, IP20, -40 °C to 70 °C.
| Parameter | Value |
|---|---|
| Digital inputs | 8; Of which 4 can be used in analog mode (0 to 10 V) |
| Digital outputs | 4; Transistor |
| Parameter | Value |
|---|---|
| Permissible range, lower limit (DC) | 20.4 V |
| Permissible range, upper limit (DC) | 28.8 V |
| Short-circuit protection | Yes; electrical (1 A) |
| Parameter | Value |
|---|---|
| Temperature, min. | -40 °C |
| Temperature, max. | 70 °C |
| Ambient temperature vs. altitude/pressure derating | Tmin ... Tmax at 1 080 hPa ... 795 hPa (-1 000 m ... +2 000 m) |
| Parameter | Value |
|---|---|
| Width | 71.5 mm |
| Height | 90 mm |
| Depth | 58 mm |
The 480-hour power reserve keeps time-of-day and retentive markers through a weekend outage.
Module dimensions: 90 mm x 71.5 mm x 58 mm, 4 SU on 35 mm DIN rail. Ethernet port and microSD slot accept LOGO! Soft Comfort V8 or newer; earlier projects can be migrated. IP20 rating; intended for panel use. Approvals include CE, UL, CSA, FM, Marine, and VDE. Complies with EN55011 Class B for residential areas.
Operating temperature from -40 °C to 70 °C, storage temperature covers a wider range; IP20 protection.
The module carries CE, UL, CSA, FM, and Marine approvals, and meets EN55011 Class B for residential EMC.
