Siemens 6ED10521FB080BA0

Siemens 6ED10521FB080BA0 LOGO!8, 12W, 8I/4O Relay, PROFINET

MPN6ED10521FB080BA0

Siemens LOGO! 8 programmable logic controller, 6ED10521FB080BA0, 24 V DC, 12 W, 0.5 A, 8 inputs, 4 relay outputs, Ethernet/PROFINET IO Device, IP20, no display.

Siemens 6ED10521FB080BA0 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

6ED10521FB080BA0 specifications
ParameterValue
Output signalRelay Output
Display typeNo Display
Terminal typeScrew Terminal
InterfaceEthernet
Voltage24 V DC
Supply voltage24 V DC
Current0.5 A
Power12 W
Frequency50 Hz
IP ratingIP20
Is profinet IO devicetrue
Is profinet IO controllerfalse
Mounting fastenerDIN Rail
Temp operating max55 °C
Temp operating min0 °C
I/O channels8
Channels12

Product details

Controller for embedded tasks

Siemens 6ED10521FB080BA0 LOGO! 8 programmable logic controller, no display. 8 digital inputs, 4 relay outputs. Ethernet with PROFINET IO. 24 V DC, 12 W (0.5 A). DIN rail mount, IP20. The relay outputs switch up to 10 A resistive and 3 A inductive, typical for the LOGO! relay output family. External fusing is required per the manufacturer's guidelines; no short-circuit protection is built in.

Rated 12 W (0.5 A) at 24 V DC. Provides 8 digital inputs and 4 relay outputs. Operating temperature range is 0 °C to 55 °C.

Panel integration

Ethernet connection supports PROFINET IO. Supply voltage 24 V DC. External fusing necessary for outputs.

Frequently asked questions

What are the key electrical ratings of this LOGO!8?

It operates from 24 V DC, draws 12 W (0.5 A), and offers 8 digital inputs plus 4 relay outputs rated for 10 A resistive or 3 A inductive switching.

MPN
6ED10521FB080BA0
