The Siemens 6ED1055-4MH08-0BA1 is a LOGO! TD text display — a 6-line FSTN panel with LED backlight and three selectable background colors, purpose-built for the LOGO! 8 modular logic controller family and later generations. Two Ethernet ports let it sit on the same network as the controller without an extra switch for the display link.
Front-panel fit and environmental range
Rated IP65 at the front, so it holds up in panel environments with occasional washdown splashes or dust — common in packaging lines, small conveyors, and machine builder panels where a full HMI is overkill. The housing is plastic and the overall depth is 38.7 mm, which keeps the back-of-panel projection short in tight enclosures. Typical power draw is 1.8 W at 24 V DC, negligible for the LOGO! power budget.
Carries CE, UL, FM, KC, and American Bureau of Shipping (ABS) approvals — accepted across European, North American, Korean, and marine applications. The product status is listed as active, so it remains in standard production and supply channels.
Sourcing note
This display is specified into the BOM for LOGO! 8-based control panels.
