Siemens 6EP1232-1AA00 — DIN Rail Power Supplies

Siemens 6EP1232-1AA00

MPN6EP1232-1AA00

********* spare part ********** SITOP PSA100E regulated power supply 60 W input: 230 V AC output: 24 V DC/2.5 A,

$356.08Ref. price · indicative, final on quote
Siemens 6EP1232-1AA00 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6EP1232-1AA00 — Electrical – Output
ParameterValue
Rated output voltage (DC)24 V
Rated current2.5 A
Rated current range0 ... 2.5 A; 2.5 A up to +45 °C, 1.25 A up to +70 °C
Output power at rated voltage/current (typ.)11 W
Output voltage characteristicControlled, isolated DC voltage
Output 1 rated voltage (DC)24 V
Output voltage adjustableYes
6EP1232-1AA00 — Electrical – Input & Efficiency
ParameterValue
Supplied active power (typ.)60 W
Efficiency84 %
Power supply network type1-phase AC
Maximum3.5 mA
6EP1232-1AA00 — Protection & Isolation
ParameterValue
Ingress protection (IP) ratingIP20
Protection classClass I
Short-circuit proof outputYes
Short-circuit protection designElectronic shutdown, automatic restart
Galvanic isolation input/outputYes
Galvanic isolation (SELV / standards)Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178
6EP1232-1AA00 — Connections
ParameterValue
Electrical connection typescrew-type terminals
Input terminalsL, N, PE: Removable screw terminal, each for 1 x 0.5 ... 2.5 mm²
Output terminals+, -: Removable screw terminal each for 1 x 0.5 ... 2.5 mm²
6EP1232-1AA00 — Mechanical
ParameterValue
Mounting methodSnaps onto DIN rail EN 60715 35x7.5/15, wall mounting
Enclosure width52 mm
Enclosure height170 mm
Enclosure depth110 mm
Side-by-side mountableYes
6EP1232-1AA00 — Environmental
ParameterValue
Operating temperature range-10 ... +70 °C; with natural convection
Storage temperature range-40 ... +85 °C
Transport temperature range-40 ... +85 °C
Current limitation of inrush current at 25 °C maximum30 A
6EP1232-1AA00 — Approvals & EMC
ParameterValue
CE markingYes
UL approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
CSA approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
NEC Class 2No
ATEX approvalNo
IECEx approvalNo
UL HazLoc approvalNo
cCSAus Class I Div 2 (hazardous loc.)No
EAC approvalYes
EMC – emission standardEN 55022 Class B
EMC – immunity standardEN 61000-6-2
6EP1232-1AA00 — Reliability & Features
ParameterValue
MTBF at 40 °C2 228 710 h
Equipment bridgingYes
Status indicators / displayGreen LED for 24 V OK
6EP1232-1AA00 — Electrical
ParameterValue
Adjustable Output Voltage23 ... 26 V
MPN
6EP1232-1AA00
