Siemens 6EP1332-5BA10 — DIN Rail Power Supplies

Siemens 6EP1332-5BA10 Power Supply, 4 A, 110-300 VDC Input

MPN6EP1332-5BA10
Active

Siemens SITOP PSU100M power supply, 6EP1332-5BA10, 4 A rated output, 110-300 VDC input, IP20, snaps onto DIN rail EN 60715.

$76.20 – $168.00Ref. price · indicative, final on quote
Siemens 6EP1332-5BA10 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6EP1332-5BA10 — Electrical – Output
ParameterValue
Rated output voltage (DC)24 V
Rated current4 A
Rated current range0 ... 4 A; +55 ... +70 °C: Derating 3%/K; at +70 °C Iout rated 2.2 A
Output power at rated voltage/current (typ.)13 W
Output voltage characteristicControlled, isolated DC voltage
Output 1 rated voltage (DC)24 V
Output voltage adjustableYes
6EP1332-5BA10 — Electrical – Input & Efficiency
ParameterValue
Supplied active power (typ.)96 W
Efficiency88 %
Power supply network type1-phase AC or DC
Maximum3.5 mA
6EP1332-5BA10 — Protection & Isolation
ParameterValue
Ingress protection (IP) ratingIP20
Protection classClass I
Short-circuit proof outputYes
Short-circuit protection designElectronic shutdown, automatic restart
Galvanic isolation input/outputYes
Galvanic isolation (SELV / standards)Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178
6EP1332-5BA10 — Connections
ParameterValue
Electrical connection typescrew-type terminals
Input terminalsL, N, PE: Removable screw terminal, each for 1 x 0.5 ... 2.5 mm²
Output terminals+: 1 screw terminal for 0.5 ... 2.5 mm²; -: 2 screw terminals for 0.5 ... 2.5 mm²
6EP1332-5BA10 — Mechanical
ParameterValue
Mounting methodSnaps onto DIN rail EN 60715 35x7.5/15
Enclosure width52.5 mm
Enclosure height80 mm
Enclosure depth100 mm
Side-by-side mountableYes
Mounting clearance, left0 mm
Mounting clearance, right0 mm
Mounting clearance, top50 mm
Mounting clearance, bottom50 mm
6EP1332-5BA10 — Environmental
ParameterValue
Operating temperature range-20 ... +70 °C; with natural convection
Storage temperature range-40 ... +85 °C
Transport temperature range-40 ... +85 °C
Climatic class (IEC 60721)Climate class 3K3, 5 … 95% no condensation
Current limitation of inrush current at 25 °C maximum34 A
6EP1332-5BA10 — Approvals & EMC
ParameterValue
CE markingYes
UL approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259; cCSAus (CSA C22.2 No. 60950-1, UL 60950-1)
CSA approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259; cCSAus (CSA C22.2 No. 60950-1, UL 60950-1)
NEC Class 2No
ATEX approvalNo
IECEx approvalNo
UL HazLoc approvalNo
cCSAus Class I Div 2 (hazardous loc.)No
EAC approvalYes
Shipbuilding approvalABS, DNV GL
EMC – emission standardEN 55022 Class B
EMC – immunity standardEN 61000-6-2
6EP1332-5BA10 — Reliability & Features
ParameterValue
MTBF at 40 °C2 726 727 h
Equipment bridgingYes; Start-up with single nominal load only
Status indicators / displayGreen LED for output voltage OK
6EP1332-5BA10 — Electrical
ParameterValue
Adjustable Output Voltage22.2 ... 26.4 V

Product details

Power Supply for DC-Bus Applications

The 4 A rating holds up to +55 °C ambient; above that, derate 3% per K, reaching 2.2 A at +70 °C — so if your enclosure runs hot, size for the derated figure, not the headline 4 A.

Clearance and Mounting

Requires 50 mm clearance above and below the unit for natural convection cooling — no forced air needed, but don't box it in. Left and right clearance is 0 mm, so units can be ganged side-by-side without spacing. IP20 rated, so it's for clean, dry enclosures only; not for washdown or outdoor locations.

Input and Protection

AC input range 100-230 V, 47-63 Hz; DC input range 85-264 V (110-300 V rated). Internal fuse protection; the feeder should use a 16 A characteristic B or 10 A characteristic C MCB. Maximum I²t is 3 A²·s. MTBF at 40 °C is 2,726,727 hours.

Frequently asked questions

What approvals does 6EP1332-5BA10 carry?

CE, UL (cULus-Listed to UL 508 and CSA C22.2 No. 107.1), CSA (cCSAus to CSA C22.2 No. 60950-1 and UL 60950-1), EAC, and DNV GL marine. Not ATEX, IECEx, or NEC Class 2.

Where can I buy 6EP1332-5BA10?

Sourced and quoted to order against an RFQ through independent distribution. Availability and current pricing confirmed at quote time.

What is the top clearance required for 6EP1332-5BA10?

50 mm above and below for natural convection cooling; 0 mm left and right allows side-by-side ganging.

Does 6EP1332-5BA10 have ATEX certification?

No, ATEX and IECEx are not listed for this unit.
