Siemens 6EP1333-1LB00

Siemens 6EP1333-1LB00 Power Supply, 5 A, 120/230 V AC

MPN 6EP1333-1LB00
NRND

Siemens SITOP power supply, 6EP1333-1LB00, 5 A rated output, 120/230 V AC input, SELV, IP20, DIN rail mount.

$59.69 – $153.51 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6EP1333-1LB00 specifications
ParameterValue
Fuse protection typeT 3,15 A/250 V (not accessible)
Voltage24 V
Power120 W
Frequency47 ... 63 Hz
Phases1-phase
IP ratingIP20
MountingSnaps onto DIN rail EN 60715 35x7.5/15
Depth120 mm
Width50 mm
Height125 mm
Efficiency86%

Product details

The Siemens 6EP1333-1LB00 is a SITOP modular power supply delivering a rated 5 A at safety extra-low voltage (SELV) output, per EN 60950-1 and EN 50178. It accepts dual-range AC input — 120 V (93–132 V) or 230 V (187–264 V) — selectable via a front-panel switch, and handles line frequencies from 47 to 63 Hz. The output is rated continuously at 5 A over 0–60 °C with natural convection; above 45 °C, derate at 2%/K. This unit snaps onto a standard DIN rail (EN 60715 35×7.5/15) and is IP20 rated, so it belongs inside a control cabinet — not in a washdown or outdoor location. The output terminals accept 0.5–2.5 mm² stranded or solid wire; input terminals are similarly sized, with L, N, and PE each on a dedicated screw clamp.

Installation notes

Mounting requires 50 mm clearance above and below the unit for convection airflow; left and right sides can be flush (0 mm clearance). The internal fuse is a T 3.15 A/250 V (not user-accessible). Siemens recommends a 6 A characteristic C miniature circuit breaker in the feeder. Off-state leakage is typically 0.4 mA, maximum 3.5 mA — negligible for most control circuits, but worth noting if you're feeding sensitive electronics that share a residual-current device.
