Siemens 6EP1333-4BA00 — Power Supplies

Siemens 6EP1333-4BA00 SITOP PSU8200, 8 A, 24 V DC, ATEX

MPN6EP1333-4BA00
Active

Siemens SITOP PSU8200, 6EP1333-4BA00, 24 V DC / 8 A, dual AC input 85-132 / 170-264 V, ATEX/IECEx/cULus hazloc, IP20, mounts on S7-1500 rail.

$135.89 – $290.00Ref. price · indicative, final on quote
Siemens 6EP1333-4BA00 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6EP1333-4BA00 key specifications
ParameterValue
Fuse protection typeT 6.3 A/250 V (not accessible)
Type of electrical connectionScrew-/spring clamp connection
Type of the power supply network1-phase AC
Voltage curve at outputControlled, isolated DC voltage
At rated input voltage 1203.7 A
At rated input voltage 2301.7 A
Output voltage at DC rated value24 V
On slow fluctuation of input voltage0.1 %
Relative overall tolerance of the voltage1 %
Product function output voltage adjustableNo
Behavior of the output voltage when switching onNo overshoot of Vout (soft start)
At rated output voltage for rated value of the output current typical21 W

All specifications

6EP1333-4BA00 additional specifications
ParameterValue
Relative control precision of the output voltage with rapid fluctuation of the input voltage by +/- 15% typical0.1 %
At Short-Circuit during operation70 ms
Response value current limitation8.4 ... 9.6 A
Design of Short-Circuit protectionElectronic shutdown, automatic restart
On Short-Circuiting during the Start-Up70 ms
At Short-Circuit during operation typical35 A
Property of the output Short-Circuit proofYes
On Short-Circuiting during the Start-Up typical35 A
Current limitation of inrush current at 25 °C maximum62 A
Buffering time for rated value of the output current in the event of power failure minimum20 ms
Supplied active power typical192 W
Number of Parallel-Switched equipment resources for increasing the power2
Line frequency45 ... 65 Hz
Depth of the enclosure129 mm
Width of the enclosure75 mm
Height of the enclosure147 mm
Product feature of the enclosure housing can be lined upYes
Removable terminal at inputYes
Removable terminal at outputYes
MTBF at 40 °C1 362 918 h
CE markingYes
UL approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 142), File E143289
CSA approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 142), File E143289
EAC approvalYes
ULhazloc approvalYes
Shipbuilding approvalABS, BV, DNV GL
Environmental category according to IEC 60721Climate class 3K3, 5 … 95% no condensation
Top40 mm
ATEXYes; ATEX (EX) II 3G Ex nA nC IIC T3 Gc
Left0 mm
IECExYes; IECEx Ex nA nC IIC T3 Gc
Right0 mm
Bottom40 mm
DNV GLYes
1 at AC85 ... 132 V
2 at AC170 ... 264 V
Typical1.3 mA
At inputL, N, PE: 1 screw terminal each for 0.5 ... 2.5 mm²
At outputL+, M: 2 spring-loaded terminals each for 0.5 to 2.5 mm²
NEC class 2No
Rated range0 ... 8 A
Rated value8 A
1 rated value50 Hz
2 rated value60 Hz
In the feederRecommended miniature circuit breaker: 16 A characteristic B or 10 A characteristic C
Initial valueAutomatic range selection
During storage-40 ... +85 °C
FM registrationYes; Class I, Div. 2, Group ABCD, T4
During operation0 ... 60 °C; with natural convection
During transport-40 ... +85 °C
MountingCan be mounted onto S7-1500 rail
Relating to ATEXIECEx Ex nA nC IIC T3 Gc; ATEX (EX) II 3G Ex nA nC IIC T3 Gc; cULus (ANSI/ISA 12.12.01, CSA C22.2 No.213) Class I, Div. 2, Group ABCD, T3, File E330455
I2t value maximum12 A²·s
Other informationSpecifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified)
Galvanic isolationSafety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178 and EN 61131-2
1 at AC rated value120 V
2 at AC rated value230 V
Protection class IPIP20
Bridging of equipmentYes
Efficiency in percent90 %
Response delay maximum1.5 s
For emitted interferenceEN 55022 Class B
Nippon kaiji kyokaiNo
For interference immunityEN 61000-6-2
Load step 10 to 90% typical5 ms
Load step 90 to 10% typical5 ms
cCSAus, class 1, division 2No
At output 1 at DC rated value24 V
For mains harmonics limitationEN 61000-3-2
Overvoltage overload capability2.3 × Vin rated, 1.3 ms
Design of input wide range inputNo
Lloyds register of shippingNo
On slow fluctuation of ohm loading0.1 %
Operating resource protection classClass I
Design of the overvoltage protectionAdditional control loop, limitation (closed loop control) at < 28.8 V
Display version for normal operationLED green for 24 V OK; LED red for error; LED yellow for stand-by
French marine classification societyYes
Operating condition of the mains bufferingat Vin = 93/187 V
Galvanic isolation between input and outputYes
American bureau of shipping europe ltd.Yes

Product details

The Siemens 6EP1333-4BA00 is a 24 V DC power supply from the SITOP PSU8200 series, rated for 8 A continuous output. It accepts dual-range AC input — 85–132 V or 170–264 V — at 45–65 Hz, with automatic range selection. The unit is designed for mounting directly on an S7-1500 rail, saving panel space. This supply carries ATEX II 3G Ex nA nC IIC T3 Gc and IECEx Ex nA nC IIC T3 Gc certifications, plus cULus hazloc approval for Class I, Div. 2, Groups A, B, C, D, T3 (File E330455). That means it is qualified for installation in Zone 2 gas environments and Division 2 locations — a common requirement for chemical, oil & gas, and pharmaceutical lines. Output terminals are spring-loaded (L+, M) accepting 0.5–2.5 mm²; input uses screw terminals for L, N, PE. The recommended upstream protection is a 16 A B-curve or 10 A C-curve MCB. Galvanic isolation provides SELV output per EN 60950-1, EN 50178, and EN 61131-2.

The unit requires 40 mm clearance above and below (top and bottom) for natural convection cooling. No side clearance is needed — left and right are 0 mm. This fits a standard 80 mm tall DIN-rail slot with the supply centered. Operating temperature range is 0–60 °C with natural convection; storage and transport range is -40 to +85 °C.

Compliance & Approvals

Full approval set: CE, cULus (UL 508, CSA C22.2 No. 142, File E143289), EAC, FM (Class I, Div. 2, Group ABCD, T4), ATEX, IECEx, and DNV GL. The ATEX and IECEx certifications cover gas group IIC, temperature class T3. The cULus hazloc listing (File E330455) covers Class I, Div. 2, Groups A, B, C, D, T3. Protection class is IP20.

Frequently asked questions

What approvals does the 6EP1333-4BA00 carry?

CE, cULus (UL 508, CSA C22.2 No. 142), EAC, FM, ATEX II 3G Ex nA nC IIC T3 Gc, IECEx Ex nA nC IIC T3 Gc, and DNV GL. The cULus hazloc listing covers Class I, Div. 2, Groups A, B, C, D, T3.

What is the maximum output current and input voltage range?

Rated output current is 8 A continuous. Input accepts dual-range AC: 85–132 V or 170–264 V, 45–65 Hz, with automatic selection.

Can this power supply be mounted on an S7-1500 rail?

Yes, the fastening method is designed for direct mounting onto an S7-1500 rail. Top and bottom clearance of 40 mm each is required for convection cooling; no side clearance is needed.
