Siemens 6EP1334-1LB00 — DIN Rail Power Supplies

Siemens 6EP1334-1LB00 Power Supply, 10 A, 120/230 V AC

MPN6EP1334-1LB00
NRND

Siemens SITOP power supply, 6EP1334-1LB00, 10 A rated output, 120/230 V AC input, 50/60 Hz, DIN rail mount, IP20.

$49.20Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026

Specifications

6EP1334-1LB00 — Electrical – Output
ParameterValue
Rated output voltage (DC)24 V
Rated current10 A
Rated current range0 ... 10 A; +45 ... +60 °C: Derating 2%/K
Output power at rated voltage/current (typ.)34 W
Output voltage characteristicControlled, isolated DC voltage
Output 1 rated voltage (DC)24 V
Output voltage adjustableYes
6EP1334-1LB00 — Electrical – Input & Efficiency
ParameterValue
Supplied active power (typ.)240 W
Efficiency89 %
Power supply network type1-phase AC
Maximum3.5 mA
6EP1334-1LB00 — Protection & Isolation
ParameterValue
Ingress protection (IP) ratingIP20
Protection classClass I
Short-circuit proof outputYes
Short-circuit protection designConstant current characteristic
Galvanic isolation input/outputYes
Galvanic isolation (SELV / standards)Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178
6EP1334-1LB00 — Connections
ParameterValue
Electrical connection typescrew-type terminals
Input terminalsL, N, PE: 1 screw terminal each for 0.5 ... 2.5 mm² single-core/finely stranded
Output terminals+, -: 2 screw terminals each for 0.5 ... 2.5 mm²
6EP1334-1LB00 — Mechanical
ParameterValue
Mounting methodSnaps onto DIN rail EN 60715 35x7.5/15
Enclosure width70 mm
Enclosure height125 mm
Enclosure depth120 mm
Side-by-side mountableYes
Mounting clearance, left0 mm
Mounting clearance, right0 mm
Mounting clearance, top50 mm
Mounting clearance, bottom50 mm
6EP1334-1LB00 — Environmental
ParameterValue
Operating temperature range0 ... 60 °C; with natural convection
Storage temperature range-40 ... +85 °C
Transport temperature range-40 ... +85 °C
Climatic class (IEC 60721)Climate class 3K3, 5 … 95% no condensation
Current limitation of inrush current at 25 °C maximum65 A
6EP1334-1LB00 — Approvals & EMC
ParameterValue
CE markingYes
UL approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
CSA approvalYes; cULus-Listed (UL 508, CSA C22.2 No. 107.1), File E197259
NEC Class 2No
ATEX approvalNo
IECEx approvalNo
UL HazLoc approvalNo
cCSAus Class I Div 2 (hazardous loc.)No
EAC approvalYes
EMC – emission standardEN 55022 Class A
EMC – immunity standardEN 61000-6-2
6EP1334-1LB00 — Reliability & Features
ParameterValue
MTBF at 40 °C2 333 396 h
Equipment bridgingYes
Status indicators / displayGreen LED for 24 V OK
6EP1334-1LB00 — Electrical
ParameterValue
Adjustable Output Voltage22.8 ... 26.4 V

Product details

The Siemens 6EP1334-1LB00 is a SITOP modular power supply delivering a rated 10 A at SELV output, with dual-range AC input covering 93–132 V and 187–264 V at 47–63 Hz. That 10 A is the full rated value across 0–10 A, but above +45 °C you derate 2%/K up to the 60 °C max — so at 55 °C ambient you lose 20% and are good for 8 A continuous. The output is safety extra-low voltage per EN 60950-1 and EN 50178, which means it's suitable for feeding control circuits and 24 V DC loads in industrial panels without extra isolation downstream. Mounting is snap-on DIN rail per EN 60715 35x7.5/15, so it drops into any standard 35 mm rail panel. Clearance needed: 50 mm top and bottom, 0 mm left and right — tight side-by-side mounting is fine. The IP20 enclosure means it's for dry indoor cabinets only, not washdown zones.

CE marked. UL/cULus-Listed under UL 508 and CSA C22.2 No. 107.1, File E197259. EAC approved. Not ATEX, not IECEx, not DNV GL, not FM registered, not UL hazardous location. No NEC Class 2 rating on the output. The galvanic isolation is SELV, so it meets the touch-safe requirements for control circuits in most industrial machinery.

Frequently asked questions

Where can I buy 6EP1334-1LB00 and how is it quoted?

We source and quote this part to order against an RFQ. Availability and current pricing are confirmed at quote time through our independent distribution channels.

What approvals does 6EP1334-1LB00 carry?

CE marked, UL/cULus-Listed (UL 508, CSA C22.2 No. 107.1, File E197259), and EAC approved. It is not ATEX, IECEx, DNV GL, FM, or UL hazardous location rated.

What are the clearance requirements for 6EP1334-1LB00?

50 mm clearance needed above and below the unit; 0 mm left and right allows side-by-side mounting on DIN rail.
