Siemens 6EP1434-2BA20

Siemens 6EP1434-2BA20 SITOP PSU6200 24V 10A Power Supply

MPN 6EP1434-2BA20
Active

Siemens SITOP PSU6200, 24 V / 10 A regulated power supply, 3-phase 400–500 V AC input, 91 % efficiency, IP20, DIN-rail mount.

$149.86 – $259.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6EP1434-2BA20 specifications
ParameterValue
Voltage24 V
Power240 W
Frequency47 ... 63 Hz
Phases3-phase
IP ratingIP20
MountingSnaps onto DIN rail EN 60715 35x7.5/15
Depth120 mm
Width70 mm
Height125 mm
Efficiency91%

Product details

The Siemens 6EP1434-2BA20 is a SITOP PSU6200 series 24 V DC power supply rated for 10 A continuous output (12 A up to +45 °C, with derating 5 %/K from +60 to +70 °C). It accepts a 3-phase 400–500 V AC input at 47–63 Hz and delivers 91 % efficiency at full load. The unit snaps onto a DIN rail EN 60715 35×7.5/15 and is IP20 rated for enclosure mounting.

The 10 A rated output is the continuous current at 25 °C ambient. If your panel runs hotter than 45 °C, you need to derate: above 60 °C, subtract 5 % per Kelvin — at 65 °C that drops you to about 7.5 A. The 16 A maximum input current tells you the upstream breaker must be sized accordingly; Siemens specifies a 3-pole C-curve MCB 3–16 A or a 3RV2 motor-protective breaker as the feeder protection. Galvanic isolation is safety extra-low voltage (SELV) per EN 60950-1 and EN 50178, with transformer isolation per EN 61558-2-16. That means the output is safe to touch and suitable for supplying control circuits, PLCs, and sensors without additional isolation barriers.

This power supply carries cULus listing under UL 508 and CSA C22.2 No. 107.1 (File E197259), plus cCSAus to UL 60950-1 and CSA C22.2 No. 60950-1. It also holds CE, EAC, C-Tick, and shipbuilding approvals from ABS and DNV GL. It is not rated for ATEX, IECEx, FM, or UL hazardous locations.

Input terminals:, L2, L3, PE — one screw terminal each, accepting 0.05–2.5 mm² single-core or finely stranded wire. Output terminals: + and -, two screw terminals each for 0.2–2.5 mm².

MPN
6EP1434-2BA20
