Siemens 6EP7133-6AB00-0BN0 SITOP PSU8200, 6 A, 50 mm

Name: 6EP7133-6AB00-0BN0
Brand: Siemens
SKU: 6EP7133-6AB00-0BN0
Availability: LimitedAvailability
Author: Indirect Spend Ivan

Specifications

6EP7133-6AB00-0BN0 — Electrical – Output
Parameter	Value
Rated output voltage (DC)	24 V
Rated current	5 A
Rated current range	0 ... 6 A; 5 A up to +60°C; +60 ... +70 °C: Derating 3%/K
Output power at rated voltage/current (typ.)	17 W
Output voltage characteristic	Controlled, isolated DC voltage
Output 1 rated voltage (DC)	24 V
Output voltage adjustable	Yes

6EP7133-6AB00-0BN0 — Electrical – Input & Efficiency
Parameter	Value
Supplied active power (typ.)	120 W
Efficiency	88 %
Power supply network type	1-phase AC
Maximum	3.5 mA

6EP7133-6AB00-0BN0 — Protection & Isolation
Parameter	Value
Ingress protection (IP) rating	IP20
Protection class	Class I
Short-circuit proof output	Yes
Short-circuit protection design	Constant current characteristic
Galvanic isolation input/output	Yes
Galvanic isolation (SELV / standards)	Safety extra-low output voltage Uout acc. to EN 60950-1 and EN 50178

6EP7133-6AB00-0BN0 — Connections
Parameter	Value
Electrical connection type	Push-in terminals
Input terminals	L, N, PE: 1 PushIn terminal each for 0.2 ... 2.5 mm² single-core/finely stranded
Output terminals	+, -: 2 PushIn terminals each for 0.2 ... 2.5 mm²

6EP7133-6AB00-0BN0 — Mechanical
Parameter	Value
Mounting method	Snaps onto DIN rail EN 60715 35x7.5/15
Enclosure width	160 mm
Enclosure height	117 mm
Enclosure depth	74 mm
Side-by-side mountable	Yes
Mounting clearance, left	0 mm
Mounting clearance, right	0 mm
Mounting clearance, top	50 mm
Mounting clearance, bottom	50 mm

6EP7133-6AB00-0BN0 — Environmental
Parameter	Value
Operating temperature range	-30 ... +70 °C; with natural convection
Storage temperature range	-40 ... +85 °C
Transport temperature range	-40 ... +85 °C
Climatic class (IEC 60721)	Climate class 3K3, 5 … 95% no condensation
Current limitation of inrush current at 25 °C maximum	45 A

6EP7133-6AB00-0BN0 — Approvals & EMC
Parameter	Value
CE marking	Yes
UL approval	Yes; cULus-Listed (UL61010-2-201, CSA C22.2 No.142); cCSAus (CSA C22.2 No. 60950-1, UL 60950-1)
CSA approval	Yes; cULus-Listed (UL61010-2-201, CSA C22.2 No.142), cCSAus (CSA C22.2 No. 60950-1, UL 60950-1)
NEC Class 2	No
ATEX approval	Yes; ATEX (EX) II 3G Ex ec nC IIC T3 Gc
IECEx approval	Yes; IECEx Ex ec nC IIC T3 Gc
UL HazLoc approval	No
cCSAus Class I Div 2 (hazardous loc.)	No
EAC approval	Yes
Shipbuilding approval	BV, DNV GL
EMC – emission standard	EN 61000-6-3 Class B
EMC – immunity standard	EN 61000-6-2

6EP7133-6AB00-0BN0 — Reliability & Features
Parameter	Value
MTBF at 40 °C	1 598 441 h
Equipment bridging	Yes
Status indicators / display	Green LED for 24 V OK

6EP7133-6AB00-0BN0 — Electrical
Parameter	Value
Adjustable Output Voltage	22.8 ... 28 V

Product details

The Siemens 6EP7133-6AB00-0BN0 is a SITOP PSU8200 power supply rated for 6 A output, with a continuous 5 A up to +60 °C and derating above that. It accepts dual AC input ranges — 85…132 V or 170…264 V — and automatically selects the range. Output is safety extra-low voltage (SELV) per EN 60950-1 and EN 50178, so it can supply control circuits without additional isolation. The 50 mm height and 0 mm left/right clearance requirements mean it packs tightly into a crowded cabinet — no side breathing gaps needed.

Certifications and approvals

This unit carries ATEX II 3G Ex ec nC IIC T3 Gc and IECEx Ex ec nC IIC T3 Gc, making it suitable for Zone 2 gas environments. UL and CSA listings cover UL 61010-2-201, CSA C22.2 No. 142, plus ITE safety standards (UL 60950-1, CSA C22.2 No. 60950-1). CE, UKCA, EAC, and C-Tick marks are also present. Marine approval from DNV GL is on file.

Output side has two PushIn terminals per polarity (+ and -) for the same wire range. The recommended upstream protective device is a B/C 6 A or 3 A miniature circuit breaker. Operating temperature range is -30…+70 °C with natural convection; storage and transport range is -40…+85 °C. The MTBF at 40 °C is 1 598 441 hours. I²t value is 3.15 A²·s, useful for fuse coordination.

Frequently asked questions

What approvals does this power supply carry?

It holds ATEX II 3G, IECEx, cULus (UL 61010-2-201, CSA C22.2 No. 142), cCSAus (UL 60950-1, CSA C22.2 No. 60950-1), CE, UKCA, EAC, C-Tick, and DNV GL marine approval.

What is the output current rating and derating?

Rated output is 6 A. At +60 °C the continuous rating is 5 A; above +60 °C up to +70 °C, derate by 3% per Kelvin.

What input voltage ranges does it accept?

Two ranges: 85…132 V AC and 170…264 V AC, with automatic selection. Line frequency is 47…63 Hz.

Will 6EP7133-6AB00-0BN0 drop into a panel specified for 6EP1336-3BA00?

Both are 50 mm wide DIN-rail power supplies from the SITOP family, but the 6EP1336-3BA00 is a higher-current unit (10 A). The 6EP7133-6AB00-0BN0 has a lower output rating and different input terminal layout — verify load current and wiring before substituting.
