Siemens 6ES7131-6BF00-2AA0 — PLC Communication Modules

Siemens 6ES7131-6BF00-2AA0 ET 200SP DI, 8 DI 24 V

MPN6ES7131-6BF00-2AA0

Siemens ET 200SP digital input module, 6ES7131-6BF00-2AA0, 8 DI, 24 V DC, P-reading, 15 x 73 x 58 mm, active current production.

Siemens 6ES7131-6BF00-2AA0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7131-6BF00-2AA0 — Identification
ParameterValue
Firmware versionV1.0
6ES7131-6BF00-2AA0 — Communication
ParameterValue
I&M data supportYes; I&M0 to I&M3
Diagnostics functionYes
6ES7131-6BF00-2AA0 — Electrical
ParameterValue
Rated value (DC)24 V
Permissible range, upper limit (DC)28.8 V
Permissible range, lower limit (DC)19.2 V
Current consumption, max.70 mA; All channels are supplied from the encoder supply
Power loss (typ.)1.6 W; 24 V, 8 inputs supplied via encoder supply
Reverse polarity protectionYes
Short-circuit protectionYes
Isolation test voltage707 V DC (type test)
6ES7131-6BF00-2AA0 — I/O
ParameterValue
Input data area1 byte
6ES7131-6BF00-2AA0 — Mechanical
ParameterValue
Width15 mm
Height73 mm
Depth58 mm

Product details

The Siemens 6ES7131-6BF00-2AA0 is an ET 200SP digital input module delivering 8 channels of 24 V DC P-reading (sink) inputs. It occupies a single slot on a BU type A0 base unit, drawing 1.6 W typical at rated voltage. Module is equipped with diagnostics (I&M data 0 to 3, diagnostic alarm, green/red DIAG LED) and supports firmware updates.

Mounts on a BU A0 base unit; module width 15 mm, height 73 mm, depth 58 mm. Shielded cables up to 1 000 m, unshielded up to 600 m; isolation tested 707 V DC type test; max consumption 70 mA from encoder supply. Supports 2-wire sensor inputs with parameterizable signal evaluation. Signal "0" threshold –30 to +5 V, signal "1" +11 to +30 V; typical input current at "1" is 6.8 mA. Short-circuit protection present on the module supply side.
