The Siemens 6ES7132-1EH00-0XB0 is an ET 200S digital output module with 16 channels, communicating over PROFIBUS DP at rates up to 6 Mbit/s. It is rated for AC 120 V load circuits, delivering up to 0.4 A per channel at 40 °C (derated to 400 mA at 60 °C). The module carries a current lifecycle status, available to order against an RFQ.
Key ratings and fit
The 16 outputs switch resistive loads at up to 10 Hz, inductive loads at 0.5 Hz. The module includes diagnostic functions and a red bus fault LED. Isolation between channels and the PROFIBUS DP bus is tested at 1 500 V AC. The usable terminal block is TB 16L AC, and the module fits horizontally at 0 to 60 °C (40°C for other orientations). Dimensions are 191 x 85.5 x 61 mm.
