Siemens 6ES7132-4BB01-0AA0 ET 200S 2-DO, PNP 0.5A

MPN6ES7132-4BB01-0AA0

Siemens ET 200S digital output module, 6ES7132-4BB01-0AA0, 2 channels PNP, 0.5 A rated per channel, 15 mm width, active production.

$66.66 – $172.00Ref. price · indicative, final on quote
Siemens 6ES7132-4BB01-0AA0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7132-4BB01-0AA0 — Outputs
ParameterValue
Digital outputs2
Output typeSource output (PNP, current-sourcing)
6ES7132-4BB01-0AA0 — Electrical
ParameterValue
Rated value (DC)24 V; From power module
Output current, resistive load, max.100 Hz
Output current at signal "1" (rated)0.5 A
Output current, max. per circuit / per module600 mA
Total output current per module, max.1 A
Output voltage at signal "1" (min.)L+ (-1 V)
Residual current at signal "0", max.0.3 mA
Power dissipation (typ.)0.4 W
Inductive shutdown voltage clamp-55 to -60 V, typ. L+( )
Load resistance, upper limit3 400 Ω
Load resistance, lower limit48 Ω
Isolation between channelsNo
Isolation between channels and backplane busYes
Isolation test voltage500 V DC
6ES7132-4BB01-0AA0 — Protection & Diagnostics
ParameterValue
Short-circuit protectionYes
Reverse polarity protectionYes; polarity reversal can lead to the digital outputs being connected through
Diagnostics functionNo
Short-circuit response threshold (typ.)0.7 to 1.8 A
Redundant load controlYes; per module
Output can drive a digital inputYes
6ES7132-4BB01-0AA0 — Performance
ParameterValue
Output switching delay 0 to 1, max.200 µs
Output switching delay 1 to 0, max.1.3 ms
Switching frequency, inductive load, max.2 Hz
Switching frequency, lamp load, max.10 Hz
6ES7132-4BB01-0AA0 — Mechanical & Connection
ParameterValue
Cable length, unshielded, max.600 m
Cable length, shielded, max.1 000 m
Width15 mm
Height81 mm
Depth52 mm
Weight (approx.)40 g

Product details

If you are sourcing the 6ES7132-4BB01-0AA0 for an ET 200S rack, this two-channel source output module delivers 0.5 A per channel with built-in short-circuit protection. It's current-production, so no last-time-buy panic — confirm fit and send an RFQ.

Panel fit and switching limits

Width 15 mm, depth 52 mm, height 81 mm; occupies one slot. Resistive load max 100 Hz, inductive load max 2 Hz, lamp load max 10 Hz; short-circuit protection triggers at 0.7 to 1.8 A.
