The 6ES7132-4BF00-4AA0: Mechanically, the module is 15 mm wide, 81 mm tall, and 52 mm deep. It mounts on the ET200S terminal block (BU type A0 or A1, depending on the power bus configuration). The depth of 52 mm means it clears the standard 60 mm DIN-rail enclosure depth with room for wiring. The transistor output is short-circuit protected per channel, which eliminates the need for external fusing on each output in most control panels — a space saver on the DIN rail. For the commissioning engineer: the module is addressed via the ET200S backplane bus; no DIP switches or rotary address selectors on this slice. The I/O map is determined by the slot position in the station configuration within TIA Portal or STEP 7.
Traceability and Documentation
From a quality-doc-control perspective, this module carries the full Siemens traceability chain — each unit has a serialized date code on the nameplate that ties back to the manufacturing batch. For compliance documentation, Siemens provides a declaration of conformity (CE) and the module is designed for use in industrial environments per IEC 61131-2. RoHS and REACH declarations are available through the Siemens Industry Online Support portal. No UL listing is stated in the evidence; if your site requires UL 508 listing, verify the module's UL file status before specifying.
