The Siemens 6ES7132-4FB00-0AB0 is a 2-channel digital output module for the ET 200S distributed I/O platform, rated for 2 A per module (signal '1' rated value). It switches resistive loads up to 10 Hz and inductive loads up to 0.5 Hz, with a zero-crossing switch active up to 25 V. Response times for both turn-on and turn-off are 15 ms max. Module isolation is tested at 2 500 V DC between channels and the backplane bus.
Panel fit and wiring
The module measures 15 mm wide by 81 mm high by 52 mm deep — a standard ET 200S electronic module footprint that clips onto the terminal block rail. Address space is 1 byte per module. Power supply: 24 V AC/DC from power module, 18 mA from backplane bus. Max power loss 4 W; module current 2 A with derating. Signal '1' threshold is L+ minus 1.5 V; residual current at signal '0' is max 3 mA. Reverse voltage protection is provided when the load voltage matches the power module supply. Each output can drive a digital input (possible control) and supports redundant load control per module.
