Siemens 6ES7132-6BH00-2BA0 ET 200SP DQ Module, 24 V DC, 8 A

MPN6ES7132-6BH00-2BA0
Active

Siemens ET 200SP DQ module, 6ES7132-6BH00-2BA0, 24 V DC, 8 A total output, current-sourcing, module-wise diagnostics, active production.

$186.83 – $203.00Ref. price · indicative, final on quote
Siemens 6ES7132-6BH00-2BA0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7132-6BH00-2BA0 — Outputs
ParameterValue
Digital outputs16
Output typeSource output (PNP, current-sourcing)
6ES7132-6BH00-2BA0 — Electrical
ParameterValue
Rated value (DC)24 V
Output current, resistive load, max.100 Hz
Output current at signal "1" (rated)0.5 A
Total output current per module, max.8 A
Permissible range, upper limit (DC)28.8 V
Permissible range, lower limit (DC)19.2 V
Residual current at signal "0", max.0.1 mA
Output current up to 60 °C, max.4 A
Power dissipation (typ.)1 W
Inductive shutdown voltage clampTyp. L+ (-50 V)
Load resistance, upper limit12 kΩ
Load resistance, lower limit48 Ω
Isolation between channelsNo
Isolation between channels and backplane busYes
Isolation test voltage707 V DC (type test)
6ES7132-6BH00-2BA0 — Protection & Diagnostics
ParameterValue
Short-circuit protectionYes
Reverse polarity protectionYes
Diagnostics functionYes
Diagnostic alarmYes
Short-circuit response threshold (typ.)0.7 to 1.3 A
Short-circuit detectionYes; Module-wise
Wire-break detectionYes; Module-wise
Redundant load controlYes
Output can drive a digital inputYes
6ES7132-6BH00-2BA0 — Performance
ParameterValue
Switching frequency, inductive load, max.2 Hz
Switching frequency, lamp load, max.10 Hz
6ES7132-6BH00-2BA0 — Environmental
ParameterValue
Operating temperature, horizontal mount, max.60 °C
Operating temperature, horizontal mount, min.0 °C
6ES7132-6BH00-2BA0 — Mechanical & Connection
ParameterValue
Cable length, unshielded, max.600 m
Cable length, shielded, max.1 000 m
Width15 mm
Height73 mm
Depth58 mm
Weight (approx.)28 g

Product details

Module in a nutshell – digital output for ET 200SP

The 6ES7132-6BH00-2BA0: Switching times are 50 µs turn-on, 100 µs turn-off, which keeps the cycle budget tight in fast handshaking applications like gripper confirmation or ejector actuation. Module-wise diagnostics report wire-break and short-circuit conditions via diagnostic alarm, plus a group error signal. I&M data (I&M0 to I&M3) is supported for asset management.

Integration notes – base unit and wiring options

Firmware version V1.0 is field-upgradable. No isochronous mode, no oversampling, no PWM output – this module is a straightforward on/off driver for loads up to 48 Ω minimum, 12 kΩ maximum (typical for solenoids, contactors, indicator lamps).

Frequently asked questions

Can 6ES7132-6BH00-2BA0 replace 6ES7522-1BH01-0AB0 in an existing panel?

No. The 6ES7132 is an ET 200SP module that requires a BU type A0 base unit and the ET 200SP backplane, while 6ES7522 is an S7-1500 module. They are not electrically or mechanically interchangeable.

What diagnostic features does this module have?

It reports module-wise wire-break and short-circuit faults, generates diagnostic alarms, and supports I&M data (I&M0 to I&M3) for asset tracking.
