Siemens 6ES7132-6GD50-0BA0 — Digital Output Modules

Siemens 6ES7132-6GD50-0BA0, 4 Relay Outputs 2 A, ET 200SP

MPN6ES7132-6GD50-0BA0

Siemens ET 200SP digital output module, 6ES7132-6GD50-0BA0, 4 relay outputs, 2 A per channel, 24 VDC coil, 15 mm width, active production.

$101.00Ref. price · indicative, final on quote
Siemens 6ES7132-6GD50-0BA0 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

6ES7132-6GD50-0BA0 — Outputs
ParameterValue
Digital outputs4
Output typeRelays
6ES7132-6GD50-0BA0 — Electrical
ParameterValue
Rated value (DC)24 V
Output current, resistive load, max.2 A
Total output current per module, max.8 A
Permissible range, upper limit (DC)28.8 V
Permissible range, lower limit (DC)19.2 V
Output current up to 60 °C, max.8 A
Power dissipation (typ.)1.2 W
Isolation between channelsYes
Isolation between channels and backplane busYes
Isolation test voltage707 V DC (type test)
6ES7132-6GD50-0BA0 — Protection & Diagnostics
ParameterValue
Short-circuit protectionNo
Diagnostics functionYes
Diagnostic alarmYes
Short-circuit detectionNo
Wire-break detectionNo
6ES7132-6GD50-0BA0 — Environmental
ParameterValue
Operating temperature, horizontal mount, max.60 °C
Operating temperature, horizontal mount, min.0 °C
6ES7132-6GD50-0BA0 — Mechanical & Connection
ParameterValue
Cable length, unshielded, max.200 m
Cable length, shielded, max.1 000 m
Width15 mm
Height73 mm
Depth58 mm
Weight (approx.)30 g

Product details

Four relay outputs in a 15 mm slice

The Siemens 6ES7132-6GD50-0BA0 is a digital output module for the ET 200SP distributed I/O system, packing four relay outputs into a 15 mm-wide housing. Each channel switches up to 2 A at 24 VDC coil voltage, with the module rated for 8 A total at 60 °C. The relay type means galvanic isolation between channels and the backplane — a practical choice when you need to separate control logic from field loads like contactors, solenoid valves, or small motors.

Base unit and mounting

This module snaps onto a BU type A0 base unit — the 2-wire connection variant. The mechanical coding element prevents inserting it into the wrong base unit slot.

Diagnostics and status feedback

A green/red DIAG LED reports module diagnostics, and individual channel status shows via green LEDs. Diagnostic alarms are supported, and I&M data (I&M0 to I&M3) is available for asset tracking. The module also reports group error status. Firmware is field-upgradeable (V1.0 as shipped).

Frequently asked questions

Where can I buy Siemens 6ES7132-6GD50-0BA0?

Submit an RFQ for your BOM quantity.

Is Siemens 6ES7132-6GD50-0BA0 compatible with ET 200SP base unit type A0?

Yes. This module is designed for BU type A0 base units, specifically the 2-wire connection variant. The mechanical coding element ensures correct slot assignment.

Is 6ES7132-6GD50-0BA0 obsolete or current?

Current.
