6ES7135-4FB52-0AB0 — datasheet specifications below.
6ES7135-4FB52-0AB0
MPN6ES7135-4FB52-0AB0
6ES7135-4FB52-0AB0 — datasheet specifications below.
$361.95 – $456.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V; From power module |
| Power loss (typ.) | 2.2 W |
| Current consumption from load voltage L+ (no load), max. | 130 mA |
| Reverse polarity protection | Yes |
| Isolation test voltage | 500 V DC |
| Isolation: between channels | No |
| Isolation: channels to backplane bus | Yes |
| Max. cable length, shielded | 200 m; Max. 20 m for TWA 100 µs |
| Parameter | Value |
|---|---|
| Resolution incl. overrange (bit, with sign), max. | 16 bit; 1 to 5 V: 14 bit, ±10 V: 15 bit + sign, ±5 V: 14 bit + sign |
| Group fault indicator (SF, red LED) | Yes |
| Parameter | Value |
|---|---|
| Height | 81 mm |
| Width | 15 mm |
| Depth | 52 mm |
| Weight (approx.) | 40 g |
Product details
MPN
6ES7135-4FB52-0AB0
