Siemens 6ES7138-4DD00-0AB0 — Digital Output Modules

Siemens 6ES7138-4DD00-0AB0 ET 200SP 2-Ch DI/DO Module, 15 mm

MPN6ES7138-4DD00-0AB0

Siemens ET 200SP, digital I/O module, 6ES7138-4DD00-0AB0, 2 channels (1 DI + 1 DO each), 24 V DC, rated input 500 mA, output 2 A per channel, 15 mm width.

$163.68Ref. price · indicative, final on quote

Add to RFQ

Siemens 6ES7138-4DD00-0AB0 datasheet (PDF)

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7138-4DD00-0AB0 — Outputs
Parameter	Value
Digital outputs	2

6ES7138-4DD00-0AB0 — Electrical
Parameter	Value
Rated value (DC)	24 V
Output current, resistive load, max.	2.5 kHz
Output current at signal "1" (rated)	2 A
Output voltage at signal "1" (min.)	L+ (-1 V)
Residual current at signal "0", max.	0.5 mA
Power dissipation (typ.)	1.8 W
Inductive shutdown voltage clamp	L+ (-50 to -65 V)
Isolation between channels	No
Isolation between channels and backplane bus	Yes
Isolation test voltage	500 V DC

6ES7138-4DD00-0AB0 — Protection & Diagnostics
Parameter	Value
Short-circuit protection	Yes
Reverse polarity protection	Yes
Short-circuit response threshold (typ.)	10 A
Output can drive a digital input	Yes

6ES7138-4DD00-0AB0 — Performance
Parameter	Value
Output switching delay 0 to 1, max.	100 µs
Output switching delay 1 to 0, max.	200 µs
Switching frequency, inductive load, max.	2 Hz
Switching frequency, lamp load, max.	10 Hz

6ES7138-4DD00-0AB0 — Mechanical & Connection
Parameter	Value
Cable length, unshielded, max.	600 m
Cable length, shielded, max.	1 000 m
Width	15 mm
Height	81 mm
Depth	52 mm
Weight (approx.)	40 g

Product details

The 6ES7138-4DD00-0AB0 is a current-production Siemens ET 200SP digital input/output slice — two channels, each bringing one digital input and one transistor-style output on the same terminal block. It sits on the ET 200SP backplane, 15 mm wide, saving rail space in dense cabinet layouts. The input side accepts 24 V DC signals (signal “1” from +11 to +30 V), draws 9 mA typical per channel, and can handle sensors up to 2-wire types without an external supply. Output side switches up to 2 A per channel with short-circuit protection built in — good for driving contactors or indicator loads directly. Cable runs: unshielded up to 600 m, shielded up to 1 000 m — enough for distributed field wiring within a plant zone.
