Siemens 6ES7138-6DB00-0BB1

Siemens 6ES7138-6DB00-0BB1 DQ High-Speed Output, 20mm

MPN 6ES7138-6DB00-0BB1
Active

Siemens ET200SP digital output module, 6ES7138-6DB00-0BB1, 24 V DC, 20 x 73 x 58 mm, PWM, pulse train, isochronous mode.

$233.68 – $696.75 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7138-6DB00-0BB1 specifications
ParameterValue
Depth58 mm
Width20 mm
Height73 mm
I/O channels2; A common 24 V encoder supply for both channels

Product details

This 6ES7138-6DB00-0BB1 is a 20 mm digital output module with 24 V outputs supporting pulse-train, PWM, and isochronous mode. Supply voltage is 24 V (L+ drop -0.8 V). Diagnostic alarms and short-circuit protection are integrated; the module is parameterizable for ON-delay, OFF-delay, and dithering (–) to match valve and actuator timing.

20 mm width and 73 mm height fit standard mounting rails; depth of 58 mm leaves clearance for wiring ducts. Typical power dissipation of 1.7 W keeps adjacent modules within derating limits without forced airflow.

Electrical characteristics

Outputs switch with a 0.8 µs max rise/fall time in high-speed mode, supporting PWM periods parameterized from 0.05 to 20 ms. Minimum load impedance is 12 Ω for standard output and 240 Ω for high-speed output; the module sinks or sources current and provides 24 bytes output data (12 per channel,).
