Siemens 6ES7141-5AF00-0BA0

Siemens 6ES7141-5AF00-0BA0 ET200eco PN 8DI/4DO, IP65/67

MPN 6ES7141-5AF00-0BA0
Active

Siemens SIMATIC ET200eco PN, digital I/O module, 8 inputs + 4 outputs, M8 connector, IP65/67, -30 to 55 °C, SIL 2. Order code 6ES7141-5AF00-0BA0.

$64.77 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7141-5AF00-0BA0 specifications
ParameterValue
IP ratingIP65
Depth40 mm
Width30 mm
Height159 mm
I/O channels4

Product details

The Siemens 6ES7141-5AF00-0BA0 is the current-production digital I/O slice in the ET200eco PN family — a field-mounted remote I/O block that connects to PROFINET via an M8 shielded bus connector. It packs 8 digital inputs (24 VDC, type 2/3) and 4 digital outputs (also 24 VDC, 0.7 A total) into a 30 x 159 x 40 mm housing rated IP65/67. That IP class means it lives directly on the machine frame or conveyor line, not in a cabinet.

Temperature range and environmental fit

Rated for -30 °C to 55 °C ambient, so it handles cold storage, freezer lines, or hot production zones without derating — no heater or forced cooling required at the module level within that span. The module draws 25 mA from the backplane with no load; total encoder supply current is capped at 0.7 A. Power loss is 1.9 W typical, manageable in sealed enclosures.

I/O behaviour and diagnostics

Input thresholds: signal 0 at -30 to +5 V, signal 1 at +11 to +30 V — wide enough for long cable runs or voltage drops. Outputs switch in 1.2 to 4.8 ms rise and fall, suitable for fast valve or indicator control. Each output has a green LED status; a combined red/green LED reports module diagnostics. Diagnostic alarm is parameterisable — you can route short-circuit or sensor-supply fault messages to the controller. Short-circuit protection is electronic per module against encoder supply faults (module-by-module). Reverse polarity on the encoder outputs is protected against destruction. Isolation tested at 707 V DC type test.

Sourcing reality

This is an active current-production part (lifecycle stage: current). No last-buy window or phase-out is announced. We quote this one to order for BOM placement or line support — volume blanket or single piece, same RFQ process.
