The 6ES7141-6BG00-0AB0: Output rating is 100 mA per channel, maximum, for a 24 V DC load. Switching delay is typically 3 ms in either direction—fast enough for most solenoid banks but not for high-speed counter drives. Per-channel isolation? Not provided—there is no isolation between channels, so a short on one output may pull down neighbours if the supply is common. Plan the load grouping accordingly.
Housed in an IP65/67 enclosure (no additional cabinet needed for splash zones). Dimensions: 175 mm tall, 60 mm wide, 49 mm deep; about 910 g. The M12 port on the connector face mates with standard PROFINET cabling. Mounting uses the usual ET 200SP base unit; the module slides onto a rail and is locked with a screw. Commissioning: after assigning the device name via DCP, the integrated switch lets you daisy-chain the next station without an external switch. The MAC and IP settings are stored locally—swap the module and the CPU re-recognises it if the topology matches.
