Siemens 6ES7143-4BF00-0AA0

Siemens 6ES7143-4BF00-0AA0 Digital Output Module, 8 DO

MPN 6ES7143-4BF00-0AA0
Active

Siemens ET 200PRO digital output module, 6ES7143-4BF00-0AA0, 8 digital outputs (4 fixed DO, 4 DIO parameterizable), 0.5 A per channel at 24 V DC, SIL 2 capable, diagnostic alarm, short-circuit protection, 45 x 130 x 35 mm.

$104.14 – $294.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7143-4BF00-0AA0 specifications
ParameterValue
Depth35 mm
Width45 mm
Height130 mm

Product details

8 outputs, 4 configurable — ET 200PRO slice

The Siemens 6ES7143-4BF00-0AA0 is an ET 200PRO digital output module with 8 digital outputs, of which 4 are fixed DO and 4 are parameterizable as digital inputs (DIO). Each output is rated 0.5 A at 24 V DC, with electronic short-circuit protection per channel and reverse polarity protection against destruction. The module supports SIL 2 per IEC 62061, making it suitable for safety-related applications up to that level when integrated into a safety-rated ET 200PRO station. It also provides a diagnostic alarm and group error (SF red LED) for fault indication.

Switching speeds and load handling

Resistive load switching is rated at 100 Hz maximum, while inductive loads drop to 0.5 Hz and lamp loads to 1 Hz. Signal transition times (0→1 and 1→0) range from 1.2 ms min to 4.8 ms max, which sets the update rate for the downstream logic. The module draws up to 20 mA from the 1L+ supply with a typical power loss of 3 W.

Physical fit and isolation

Channel-to-channel isolation is not provided (no isolation between channels), but the module is isolation-tested at 707 V DC (type test). Unshielded cable runs up to 30 m are permitted.
