The 6ES7145-4FF00-0AB0: Powered from 24 V DC, it pulls up to 65 mA from the supply and 10 mA from the backplane bus. Power loss runs 1.7 W typ. Address space is 8 bytes. Supports both two-wire and four-wire voltage connections.
Output specs and protection
Voltage outputs are short-circuit protected per channel, electronic to chassis, with a max short-circuit current of 50 mA. Minimum load is 1 000 Ω. Resistive load response 0.1 ms; capacitive load 6 ms. Isolation tested at 707 V DC between channels and backplane bus. Output ranges cover the standard industrial signals: 0 to 10 V, 1 to 5 V, and -10 to +10 V. Accuracy ±0.15 % relative to output range. Shielded cable max 30 m.
Diagnostics and configuration
Parameterizable diagnostic alarm reports faults per channel. Group error SF (red) LED on the front. Substitute values can be set. Diagnostic information is readable via the bus. Short-circuit detection is per channel, but not active in the zero range — watch the dead band. No hardware interrupt, no wire-break detection. Reverse polarity protection is fitted against destruction. The module is isolated between channels and backplane.
