Siemens 6ES7147-4JD00-0AB0 — PLC I/O & Expansion Modules

Siemens 6ES7147-4JD00-0AB0 4-Port IO-Link Master, IP65/67

MPN6ES7147-4JD00-0AB0

Active

Siemens 6ES7147-4JD00-0AB0, IO-Link master module for SIMATIC ET 200SP, 4 ports, IP65/67, 24V DC, 2.6W.

$193.04 – $567.72Ref. price · indicative, final on quote

Add to RFQ

Siemens 6ES7147-4JD00-0AB0 datasheet (PDF)

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7147-4JD00-0AB0 — Electrical
Parameter	Value
Rated value (DC)	24 V
Power loss (typ.)	2.6 W
Short-circuit protection	Yes; per module, electronic
Reverse polarity protection	Yes; against destruction; load increasing
Isolation test voltage	707 V DC (type test)
Isolation: between channels	No

6ES7147-4JD00-0AB0 — Performance
Parameter	Value
Diagnostic alarm	Yes
Diagnostics function	Yes
Group fault indicator (SF, red LED)	Yes

6ES7147-4JD00-0AB0 — Environmental
Parameter	Value
IP protection rating	IP65/67

6ES7147-4JD00-0AB0 — Mechanical
Parameter	Value
Height	130 mm
Width	45 mm
Depth	35 mm
Weight (approx.)	150 g

Product details

4-Port IO-Link Master for ET 200SP

Siemens 6ES7147-4JD00-0AB0 is a 4-port IO-Link master module for the SIMATIC ET 200SP I/O system. Transmission rates up to 230.4 kBaud (COM3). Rated IP65/67. Each port can be operated as a standard digital input (DI) or output (DQ max 100 mA per channel). The module supplies power to sensors and actuators via ports: X1 and X2 share a total of 2 A, X3 and X4 share another 2 A. Diagnostics per channel include wire-break and short-circuit detection, with individual LED indicators for channel status and group error. The module draws 2.6 W typical and requires 24 VDC supply with reverse-polarity protection.

Frequently asked questions

What diagnostics are available per channel?

Each port can detect wire-break and short-circuit conditions channel by channel. LEDs show channel status and group error (SF) for quick fault isolation.
