Siemens 6ES7148-6JA00-0AB0 — PLC Communication Modules

Siemens 6ES7148-6JA00-0AB0 ET 200SP IO-Link Master, 4 Ports

MPN6ES7148-6JA00-0AB0
Active

Siemens ET 200SP IO-Link master module, 6ES7148-6JA00-0AB0, 4 M12 ports, 24 V DC, 8 W, current lifecycle.

$745.00 – $1,003.65Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7148-6JA00-0AB0 — Communication
ParameterValue
Transmission rate, max.100 Mbit/s
TCP/IP supportNo
Diagnostics functionYes
6ES7148-6JA00-0AB0 — Electrical
ParameterValue
Rated value (DC)24 V
Permissible range, upper limit (DC)28.8 V
Permissible range, lower limit (DC)20.4 V
Power loss (typ.)8 W
Reverse polarity protectionYes
Short-circuit protectionYes; Electronic
6ES7148-6JA00-0AB0 — Environmental
ParameterValue
IP protection degreeIP65/67
6ES7148-6JA00-0AB0 — Mechanical
ParameterValue
Width60 mm
Height175 mm
Depth49 mm

Product details

The Siemens 6ES7148-6JA00-0AB0 is an ET 200SP IO-Link master that puts four M12 ports on PROFINET. It handles IO-Link devices (DI and DQ) and brings diagnostics, MRP ring redundancy, and LLDP into the same slice. Rated for 24 V DC, pulling about 8 W typical. If you're wiring a line with IO-Link sensors or actuators and need a compact distributed slave, this is the part.

It packs a group error LED (SF/MT), diagnostic alarm, and supports autocrossing and short-circuit detection on the M12 ports. The integrated switch handles four ports with full autonegotiation. If you need PROFINET CBA or EtherNet/IP, this module doesn't do those – it's pure PROFINET IO.

Frequently asked questions

Will it drop into a panel that was specified for 6ES7142-4BD00-0AA0?

No, the 6ES7142-4BD00-0AA0 is a digital input module, not an IO-Link master. Different function and wiring, so rewiring is required.
