Siemens 6ES7174-0AA10-0AA0

Siemens 6ES7174-0AA10-0AA0 Encoder Interface Module, 24 V, 7

MPN 6ES7174-0AA10-0AA0

Siemens 6ES7174-0AA10-0AA0, Encoder Interface Module, 24 V DC supply, 5 V differential RS422 input, 750 kHz max pulse frequency, 160 x 125 x 118 mm.

$1,173.48 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7174-0AA10-0AA0 specifications
ParameterValue
Input voltage5 V difference signal (phys. RS 422)
Output current-3 to +3 mA
Depth118 mm
Width160 mm
Height125 mm

Product details

What this module does in the cabinet

This Siemens 6ES7174-0AA10-0AA0 is an encoder interface module for SIMATIC S7-300 systems. It reads incremental and absolute encoders via RS422 5 V differential signals, supporting Gray or binary code with A/B and zero-mark traces. Pulse frequency up to 750 kHz, clock parameterizable to 1.5 MHz.

Supply and signal details

Draws 12 W typical from a 24 V DC supply (L+). The 5 V differential input (RS422) is used for encoder data; signal levels for logic '0' are -3 to +5 V, for logic '1' are +11 to +30 V. Output current is limited to 60 mA maximum per channel, short-circuit proof with minimum 3.3 kΩ load. Two-wire sensor inputs and a bipolar ±10 V analog input expand the feedback options.

MPN
6ES7174-0AA10-0AA0
