Siemens 6ES7183-0AA01-0XA0

6ES7183-0AA01-0XA0 SIMATIC DP IM 183-1, 12 Mbit/s, SPC3

MPN 6ES7183-0AA01-0XA0

Siemens SIMATIC DP IM 183-1 PROFIBUS DP slave module, 12 Mbit/s, 5 V DC, 250 mA. SPC3 ASIC, 80C32 CPU, 32 KB SRAM, 64 KB EPROM.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7183-0AA01-0XA0 specifications
ParameterValue
Width86 mm
Height76 mm

Product details

PROFIBUS DP slave with SPC3 ASIC

The 6ES7183-0AA01-0XA0: This SIMATIC DP IM 183-1 is a slave module for PROFIBUS-DP networks, designated as a spare part by Siemens. It uses the SPC3 ASIC and supports a transmission rate up to 12 Mbit/s, making it suitable for high-speed slave applications in distributed automation systems.

Processor and memory stack

The module is built around an 80C32 microcontroller running at 20 MHz, paired with 32 KB SRAM and 64 KB EPROM. Firmware scope ranges from 4 to 24 KB inclusive of test programs. This provides deterministic response for slave nodes under PROFIBUS DP cycle times.

Supply and power budget

Operates from a 5 V DC supply rail, drawing typically 250 mA. This consumption fits within the backplane capacity of most SIMATIC DP master stations; plan the 5 V budget on the rack accordingly.

MPN
6ES7183-0AA01-0XA0
