Siemens 6ES7222-1AD30-0XB0

Siemens 6ES7222-1AD30-0XB0 SIMATIC S7-1200 SB 1222, 4 DQ, 5V

MPN 6ES7222-1AD30-0XB0
Active

Siemens SIMATIC S7-1200, Signal Board SB 1222, 4 digital outputs, 5V DC, 200 kHz, MOSFET solid-state, 0.1 A per channel.

$52.07 – $129.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

6ES7222-1AD30-0XB0 specifications
ParameterValue
Depth21 mm
Width38 mm
Height62 mm
In groups of4

Product details

The 6ES7222-1AD30-0XB0 is a SIMATIC S7-1200 Signal Board SB 1222 packing four solid-state digital outputs on a 5 V DC rail, switching at 200 kHz. Each output is rated 0.1 A resistive — enough for high-speed signaling to downstream logic or low-power actuators, not for driving contactors or solenoids directly. The MOSFET stage is current-sinking or current-sourcing, so it adapts to both NPN and PNP field wiring without a pull-up resistor swap. It draws 35 mA from the 5 V backplane bus and dissipates 0.5 W typical — negligible for the S7-1200 power budget, meaning it won't crowd out other signal boards on the same CPU. The 21 mm depth and 38 mm width keep it flush with the CPU profile, so it doesn't overhang the DIN rail or block adjacent modules. That covers most cabinet environments short of a foundry wall or freezer tunnel. The 95 % humidity ceiling at 25 °C (non-condensing) handles washdown-adjacent panels, though the board itself isn't IP-rated for direct spray.

Carries cULus, UL, CSA, CE, FM, KC, marine, and RCM approvals — enough for machinery export to North America, Europe, Korea, Australia, and marine-class vessels. The lifecycle stage is current, so this is still an active catalog number with no announced end-of-life.

MPN
6ES7222-1AD30-0XB0
