Siemens 6ES7222-1BH30-0XB0 — Digital Output Modules

Siemens 6ES7222-1BH30-0XB0 16DO 24VDC 0.5A, -40 to 70°C

MPN6ES7222-1BH30-0XB0

Siemens SIMATIC S7-1200, SM 1222, 16 digital outputs, 24 V DC, 0.5 A, with diagnostics, IP20, -40 to 70 °C, current production.

$118.11 – $219.00Ref. price · indicative, final on quote
Siemens 6ES7222-1BH30-0XB0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7222-1BH30-0XB0 — Outputs
ParameterValue
Digital outputs16
6ES7222-1BH30-0XB0 — Electrical
ParameterValue
Rated value (DC)24 V
Output current, resistive load, max.0.5 A
Output current at signal "1" (rated)0.5 A
Permissible range, upper limit (DC)28.8 V
Permissible range, lower limit (DC)20.4 V
Output voltage at signal "1" (min.)20 V DC
Residual current at signal "0", max.10 µA
Current consumption from backplane bus (5 V DC), max.140 mA
Power dissipation (typ.)2.5 W
Inductive shutdown voltage clamptyp. (L+) -48 V
Isolation between channels and backplane bus500 V AC
Isolation, channels in groups of1
6ES7222-1BH30-0XB0 — Protection & Diagnostics
ParameterValue
Short-circuit protectionNo; to be provided externally
Diagnostics functionYes
Diagnostic alarmYes
6ES7222-1BH30-0XB0 — Performance
ParameterValue
Output switching delay 0 to 1, max.50 µs
Output switching delay 1 to 0, max.200 µs
Switching frequency, inductive load, max.0.5 A
Switching frequency, lamp load, max.5 W
6ES7222-1BH30-0XB0 — Environmental
ParameterValue
Operating temperature, horizontal mount, max.55 °C
Operating temperature, horizontal mount, min.0 °C
6ES7222-1BH30-0XB0 — Mechanical & Connection
ParameterValue
Cable length, unshielded, max.150 m
Cable length, shielded, max.500 m
Width45 mm
Height100 mm
Depth75 mm
Weight (approx.)220 g

Product details

Module identity & key ratings

The Siemens 6ES7222-1BH30-0XB0 is a 16-point digital output module for the SIMATIC S7-1200 family, rated 24 V DC and 0.5 A per output resistive or inductive. Diagnostic alarm and status feedback are built-in, but short-circuit protection must be added externally – the module itself provides none.

The 0.5 A per channel is a per-output limit, not the sum. At 55 °C horizontal or 45 °C vertical you can still source the full 0.5 A from each of the 16 outputs – no global derating until ambient exceeds those thresholds. Response times are sharp: 50 µs turn-on, 200 µs turn-off, which suits solenoid banks and relay coils operating below 50 Hz. At 24 V DC the module draws 2.5 W typical from the backplane – budget that in your 24 V supply sizing.

Mounting & wiring notes

The module is 45 × 100 × 75 mm, mounts on the DIN rail, and requires a front connector. Unshielded cable runs up to 150 m; shielded up to 500 m.

Frequently asked questions

Will the 6ES7223-1BL32-0XB0 drop in without rewiring?

No. That is a combined 16-input/16-output module with a different pinout and channel count. Replacing the 16DO module with the combined version requires rewiring the connector and reconfiguring the I/O in the PLC program.

What are the maximum and minimum operating temperatures?

The module operates from –40 °C to 70 °C ambient. For horizontal mounting the maximum is 55 °C; for vertical mounting it derates to 45 °C.

Does the module have short-circuit protection?

No. Short-circuit protection must be provided externally – typically a PTC or miniature circuit breaker on each output group.
