8 Relay Outputs, 10 A per Common, -40 to 70 °C
The module draws 4.5 W typ from the backplane.
Switching Limits and External Protection
Each relay output is rated 2 A max on resistive or inductive loads. Lamp loads are limited to 30 W on DC and 200 W on AC — a practical ceiling for pilot lights and indicator banks. The module has no internal short-circuit protection; an external fuse or breaker must be provided per channel group. Switching times are 10 ms max for both turn-on and turn-off. Diagnostic alarm output is available for monitoring. The relay coil isolation between different circuits is tested at 750 V AC for 1 minute.
Approvals and Compliance Coverage
The module carries cULus, CE, UL, CSA, FM, KC, RCM (C-TICK), and marine approvals — a global compliance set that covers most industrial, marine, and hazardous-location installations without additional certification work.
Mechanical Fit and Wiring
Unshielded cable runs up to 150 m are permitted; shielded runs up to 500 m. The plastic housing withstands a 0.3 m drop five times in its packaging.
