Siemens 6ES7223-1PH32-0XB0 — PLC I/O & Expansion Modules

Siemens 6ES7223-1PH32-0XB0 S7-1200 SM1223, -40..70°C

MPN6ES7223-1PH32-0XB0
Active

Siemens S7-1200 SM1223 combination module, 6ES7223-1PH32-0XB0, 8 relay outputs, -40 to 70 °C, 45 mm width, cULus/CE/FM/marine/UL/CSA approvals.

$132.08 – $345.06Ref. price · indicative, final on quote
Siemens 6ES7223-1PH32-0XB0 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

6ES7223-1PH32-0XB0 — I/O
ParameterValue
Digital inputs8
Digital outputs8
6ES7223-1PH32-0XB0 — Electrical
ParameterValue
Rated value (DC)5 V DC to 30 V DC
Permissible range, lower limit (DC)20.4 V
Permissible range, upper limit (DC)28.8 V
For signal "1"15 V DC at 2.5 mA
For signal "0"5 V DC at 1 mA
Current for signal "1" (typ.)4 mA
Max.70 °C
Power loss (typ.)5.5 W
Current consumption from backplane bus (5 V DC), max.145 mA
Current consumption from load voltage L+ (no load), max.4 mA/input 11 mA/relay
Short-circuit protectionNo; to be provided externally
Isolation: between channelsRelays
Isolation: channels to backplane bus1 500 V AC for 1 minute
Max. cable length, shielded500 m
Max. cable length, unshielded150 m
6ES7223-1PH32-0XB0 — Performance
ParameterValue
ParameterizableYes
Diagnostic alarmYes
6ES7223-1PH32-0XB0 — Environmental
ParameterValue
IP protection ratingIP20
Min.-40 °C
6ES7223-1PH32-0XB0 — Mechanical
ParameterValue
Height100 mm
Width45 mm
Depth75 mm
Weight (approx.)230 g
6ES7223-1PH32-0XB0 — Approvals
ParameterValue
CE markYes
6ES7223-1PH32-0XB0 — Specifications
ParameterValue
Rated value (AC)5 V AC to 250 V AC
Horizontal Installation, Max.60 °C

Product details

The Siemens 6ES7223-1PH32-0XB0 is a DC-input/relay-output combination module for the S7-1200 system, providing 8 relay outputs and digital inputs in a 45 mm-wide housing. Rated for -40 to 70 °C, it carries cULus, CE, FM, KC, UL, CSA, marine, and RCM approvals—covering most global panel requirements.

Input/output characteristics

Inputs switch at a 15 V DC threshold (signal '1', 2.5 mA), compatible with standard 24 V DC sensors. Outputs handle 5–250 V AC or 5–30 V DC relay loads, up to 30 W DC / 200 W AC on lamp loads. Cabling distances: 500 m shielded, 150 m unshielded. Power draw is 5.5 W typical.

Marked as current production. Available through standard Siemens distribution channels. For BOM-frozen projects, confirm lead time against your schedule.
