Siemens SIMATIC S7-200 SMART PROFIBUS DP Slave module, 6ES7288-7DP01-0AA0, 24 VDC, 1 RS-485 interface, 9.6 KB to 12 MB, 81 × 45 × 100 mm.
| Parameter | Value |
|---|---|
| Width | 45 mm |
| Height | 100 mm |
| Depth | 81 mm |
| Parameter | Value |
|---|---|
| TCP (IP) | No |
| PROFIBUS | Yes |
| Weight, approx. | 176.2 g |
| Power loss, typ. | 2.5 W |
| Rated value | 24 V |
| Type of supply voltage | DC |
| Current consumption, max. | 30 mA |
| Current consumption, typ. | 15 mA |
| Number of RS 485 interfaces | 1 |
| Supports protocol for PROFINET IO | No |
| Permissible range, lower limit | 20.4 V |
| Permissible range, upper limit | 28.8 V |
| Number of industrial ethernet interfaces | 0 |
The Siemens 6ES7288-7DP01-0AA0 is a PROFIBUS DP slave module that slots into a SIMATIC S7-200 SMART system, adding a single RS-485 interface running 9.6 KB to 12 MB. It is a pure DP slave — no PROFINET, no TCP/IP, no Ethernet ports. The module draws 15 mA typical, 30 mA max from the 24 VDC backplane, with a permissible supply range of 20.4 to 28.8 VDC.
The module is 81 mm deep, 45 mm wide, and 100 mm tall. It weighs 176.2 g and consumes 2.5 W typical, 30 mA max from the 24 VDC supply.
It supports PROFIBUS DP/MPI over a single RS-485 interface, with baud rates from 9.6 KB to 12 MB. It does not support PROFINET, TCP/IP, or Ethernet.
Rated 24 VDC, with a permissible range of 20.4 VDC to 28.8 VDC.
