Siemens 6ES7322-1HH00-0AA0

Siemens 6ES7322-1HH00-0AA0 SM 322, 16 Relay DO, EOL

MPN 6ES7322-1HH00-0AA0
End of Life

Siemens SIMATIC S7-300 SM 322 digital output module, 6ES7322-1HH00-0AA0, 16 relay outputs (2 x 8), optically isolated, 20-pin front connector.

$114.30 – $261.00 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Product details

16 relay outputs in two isolated groups

The 6ES7322-1HH00-0AA0 is a SIMATIC S7-300 SM 322 digital output module carrying 16 relay outputs, arranged as two electrically isolated groups of 8 (2 x 8 DO). Each group connects via the 20-pin front connector, and the relay contacts are optically isolated from the backplane bus — meaning a short on one output group won't drag down the CPU or the other group.

Lifecycle status: eol_hot

What the relay outputs mean for your panel

The 16 relay outputs are rated for AC and DC loads per the contact rating. The two isolated groups allow mixing load voltages on the same module. The 20-pin front connector matches the standard S7-300 wiring scheme; the module snaps onto the DIN rail in the same footprint as any SM 322.
