6ES7322-5GH00-0AB0 - Siemens
MPN6ES7322-5GH00-0AB0
End of Life
SIMATIC S7-300, Digital output SM 322, isolated, 16 DO (solid-state relay), 24-48 V AC/DC; 0.5 A with single rooting, 1x 40-pole
$1,198.00Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Outputs
| Parameter | Value |
|---|---|
| Digital outputs | 16 |
Electrical
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V; 24 / 48 |
| Output current, resistive load, max. | 10 Hz |
| Output current at signal "1" (rated) | 0.5 A |
| Permissible range, upper limit (DC) | 57.6 V |
| Permissible range, lower limit (DC) | 20.4 V |
| Output voltage at signal "1" (min.) | L+ (-0.25 V) |
| Residual current at signal "0", max. | 10 µA |
| Output current up to 60 °C, max. | 0.5 A; 8 A per module |
| Current consumption from backplane bus (5 V DC), max. | 100 mA |
| Power dissipation (typ.) | 2.8 W |
| Isolation between channels | Yes |
| Isolation between channels and backplane bus | Yes; Optocoupler |
| Isolation, channels in groups of | 1 |
| Isolation test voltage | 1 500 V AC |
Protection & Diagnostics
| Parameter | Value |
|---|---|
| Short-circuit protection | No; to be provided externally |
| Reverse polarity protection | Yes |
| Diagnostics function | Yes; Parameterizable |
| Diagnostic alarm | Yes; Parameterizable |
| Redundant load control | Yes |
| Output can drive a digital input | Yes |
Performance
| Parameter | Value |
|---|---|
| Output switching delay 0 to 1, max. | 6 ms |
| Output switching delay 1 to 0, max. | 3 ms |
| Switching frequency, inductive load, max. | 0.5 Hz |
| Switching frequency, lamp load, max. | 0.5 Hz |
Mechanical & Connection
| Parameter | Value |
|---|---|
| Cable length, unshielded, max. | 600 m |
| Cable length, shielded, max. | 1 000 m |
| Width | 40 mm |
| Height | 125 mm |
| Depth | 120 mm |
| Weight (approx.) | 260 g |
MPN
6ES7322-5GH00-0AB0
