6ES7326-2BF40-0AB0
MPN6ES7326-2BF40-0AB0
End of Life
SIMATIC S7, DIGITAL OUTPUT SM 326, DO 8 X DC 24V/2A PM FAILSAFE DIGITAL OUTPUTS P-M SWITCHING UP TO CATEGORY 4 (EN954-1)/ SIL3 (IEC61508)/PLE (ISO13849), 1 X 40 PIN
$594.36Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jul 2026
Specifications
Outputs
| Parameter | Value |
|---|---|
| Digital outputs | 8 |
Electrical
| Parameter | Value |
|---|---|
| Rated value (DC) | 24 V; 2L+, 3L+ |
| Output current, resistive load, max. | 30 Hz |
| Output current at signal "1" (rated) | 2 A |
| Output voltage at signal "1" (min.) | L+ (-1.0 V) |
| Residual current at signal "0", max. | 0.5 mA |
| Output current up to 60 °C, max. | 5 A |
| Current consumption from backplane bus (5 V DC), max. | 100 mA |
| Power dissipation (typ.) | 12 W |
| Inductive shutdown voltage clamp | L+ (-33 V) |
| Isolation between channels | Yes |
| Isolation between channels and backplane bus | Yes |
| Isolation, channels in groups of | 4 |
| Isolation test voltage | 500 V DC/350 V AC |
Protection & Diagnostics
| Parameter | Value |
|---|---|
| Short-circuit protection | Yes |
| Reverse polarity protection | No |
| Diagnostic alarm | Yes; Parameterizable |
Performance
| Parameter | Value |
|---|---|
| Switching frequency, inductive load, max. | 2 Hz |
| Switching frequency, lamp load, max. | 10 Hz |
Mechanical & Connection
| Parameter | Value |
|---|---|
| Cable length, unshielded, max. | 50 m |
| Cable length, shielded, max. | 30 m |
| Width | 80 mm |
| Height | 125 mm |
| Depth | 120 mm |
| Weight (approx.) | 465 g |
MPN
6ES7326-2BF40-0AB0
