6ES7340-1AH01-0AE0 - Siemens
MPN6ES7340-1AH01-0AE0
End of Life
SIMATIC S7-300, CP 340 COMMUNICATION PROCESSOR WITH RS232C INTERFACE (V.24) INCL. CONFIG. PACKAGE ON CD
$200.66 – $472.00Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Electrical
| Parameter | Value |
|---|---|
| Current consumption from backplane bus (5 V DC), max. | 165 mA |
Mechanical
| Parameter | Value |
|---|---|
| Height | 125 mm |
| Width | 40 mm |
| Depth | 120 mm |
| Weight (approx.) | 300 g |
Other specifications
| Parameter | Value |
|---|---|
| 3964 | 1 024 byte |
| ASCII | 1 024 byte |
| Power loss, max. | 0.85 W |
| Cable length, max. | 15 m |
| Supported printers | HP-Deskjet, HP-Laserjet, IBM-Proprinter, user-defined |
| Interfaces (bus type) | RS 232C (V.24) |
| Number of interfaces | 1; Isolated |
| FB length in RAM, max. | 2 700 byte; Data communication, sending and receiving |
| Transmission rate, max. | 19.2 kbit/s |
| Transmission rate, min. | 2.4 kbit/s |
| With printer driver, max. | 9.6 kbit/s |
| With ASCII protocol, max. | 9.6 kbit/s |
| With 3964 (R) protocol, max. | 19.2 kbit/s |
MPN
6ES7340-1AH01-0AE0
