Siemens 6ES7352-1AH02-0AE0 — PLC I/O & Expansion Modules

Siemens 6ES7352-1AH02-0AE0 FM 352-5 Cam Controller, EOL

MPN6ES7352-1AH02-0AE0

End of Life

Siemens SIMATIC S7-300 FM 352-5 high-speed Boolean processor and cam controller, 24 V DC, 4 digital inputs, 13 digital outputs, end-of-life.

$855.98 – $1,804.00Ref. price · indicative, final on quote

Add to RFQ

Siemens 6ES7352-1AH02-0AE0 datasheet (PDF)

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7352-1AH02-0AE0 — I/O
Parameter	Value
Digital inputs	4
Digital outputs	13

6ES7352-1AH02-0AE0 — Electrical
Parameter	Value
Rated value (DC)	24 V
For signal "1"	+11 to +30V
For signal "0"	-30 to +5 V
Current for signal "1" (typ.)	9 mA
Max.	70 °C
Power loss (typ.)	8.1 W
Current consumption from backplane bus (5 V DC), max.	100 mA
Current consumption from load voltage L+ (no load), max.	200 mA
Short-circuit protection	Yes

6ES7352-1AH02-0AE0 — Environmental
Parameter	Value
Min.	-40 °C

6ES7352-1AH02-0AE0 — Mechanical
Parameter	Value
Height	125 mm
Width	80 mm
Depth	120 mm
Weight (approx.)	550 g

Product details

Cam control capability

The 6ES7352-1AH02-0AE0: Handles position-driven cam tracks via incremental (symmetrical or asymmetrical) or absolute SSI encoders. Input frequency reaches 50 kHz with 25 m cable; at the full 100 m shielded length it runs 25 kHz. SSI telegram length is parameterizable for 13 or 25 bits. Four digital inputs and 13 digital outputs make up the switching interface. The module draws power from both the 5 V DC backplane bus (up to 100 mA) and an external 24 V DC supply — no single point of power for the cam logic.
