What it is and what it does
The Siemens 6ES7444-1MX00-0XE0 is a SIMATIC S7-400 communication module CP 444 designed to connect an S7-400 rack to Industrial Ethernet using the MAP 3.0 protocol architecture, based on the transport protocol per ISO 8073 class 4. It communicates at up to 10 Mbit/s and connects via a 15-pin sub-D socket that supports automatic switchover between AUI and industrial twisted-pair media. The module supports S7 extended communication, drawing up to 3.1 A from the 5 V DC backplane bus, with a typical power loss of 15.6 W.
Fit and environmental limits
Rated for operation from 0 °C to 70 °C, with a maximum humidity of 80 % at 25 °C (no condensation). Vibration tested per IEC 60068-2-6: 10 to 58 Hz at 0.0035 mm constant amplitude, 58 to 500 Hz at 0.5 g constant acceleration.
Sourcing and lifecycle
This part is classified as mature in its lifecycle, meaning it is not in active new-production but remains available through qualified sourcing channels. Sourced to order against an RFQ — confirm fit with your BOM line before committing.
