Siemens 6ES7515-2AM01-0AB0 — PLCs (Programmable Logic Controllers)

Siemens 6ES7515-2AM01-0AB0 CPU 1515-2 PN, 32KB IO

MPN6ES7515-2AM01-0AB0

Siemens SIMATIC S7-1500, CPU 1515-2 PN, 6ES7515-2AM01-0AB0, 32 KB inputs/outputs process image, 2× PROFINET, MRP, -40...70 °C.

$984.00Ref. price · indicative, final on quote
Siemens 6ES7515-2AM01-0AB0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7515-2AM01-0AB0 — Processor & Memory
ParameterValue
Execution time, bit operations (typ.)30 ns
Execution time, word operations (typ.)36 ns
Execution time, floating-point arithmetic (typ.)192 ns
Size, max.16 kbyte
6ES7515-2AM01-0AB0 — I/O
ParameterValue
Input data area32 kbyte; All inputs are in the process image
Output data area32 kbyte; All outputs are in the process image
6ES7515-2AM01-0AB0 — Programming
ParameterValue
Programming language: FBDYes
Programming language: LADYes
Programming language: SCLYes
6ES7515-2AM01-0AB0 — Electrical
ParameterValue
Rated value (DC)24 V
Current consumption (rated)0.8 A
Permissible range, lower limit (DC)19.2 V
Permissible range, upper limit (DC)28.8 V
Power loss (typ.)6.3 W
6ES7515-2AM01-0AB0 — Environmental
ParameterValue
Installation altitude, max.5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Temperature, min.-40 °C
Temperature, max.70 °C
Operating temperature, min. (horizontal mounting)0 °C
Operating temperature, max. (horizontal mounting)60 °C; Display: 50 °C, at an operating temperature of typically 50 °C, the display is switched off
6ES7515-2AM01-0AB0 — Mechanical
ParameterValue
Width70 mm
Height147 mm
Depth129 mm
Weight (approx.)830 g

Product details

The 6ES7515-2AM01-0AB0: Two PROFINET ports at 100 Mbps, MRP-capable for ring redundancy, but no PROFIsafe integrated – safety loops will need a separate F-CPU. Built-in PID temperature and valve controllers save a slot versus adding an external loop controller.

Panel fit

Fits the standard S7-1500 form factor: 70 mm wide × 147 mm tall × 129 mm deep. Ambient range -40 to 70 °C, so it's happy in a hot cabinet or cold warehouse. Up to 8 communication modules can be added via the backplane (PROFIBUS, additional PROFINET, Ethernet), giving flexibility for legacy fieldbuses.

Frequently asked questions

What is the process image size of the 6ES7515-2AM01-0AB0?

It has 32 KB each for inputs and outputs, all in the process image.

Does the 6ES7515-2AM01-0AB0 support PROFIsafe?

No. This CPU does not have integrated PROFIsafe; safety functions require a separate F-CPU.

What is the operating temperature range?

The CPU is rated for -40 to 70 °C ambient, allowing use in a wide range of environments.

MPN
6ES7515-2AM01-0AB0
