Siemens 6ES7515-2TM01-0AB0 — PLCs (Programmable Logic Controllers)

Siemens 6ES7515-2TM01-0AB0 S7-1500 CPU, -40 to 70°C

MPN6ES7515-2TM01-0AB0

Siemens S7-1500 CPU 1515-2 PN, 6ES7515-2TM01-0AB0, DCP/DNS, 32 kB I/O, -40 to 70 °C.

$2,743.20Ref. price · indicative, final on quote
Siemens 6ES7515-2TM01-0AB0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7515-2TM01-0AB0 — Processor & Memory
ParameterValue
Execution time, bit operations (typ.)30 ns
Execution time, word operations (typ.)36 ns
Execution time, floating-point arithmetic (typ.)192 ns
Size, max.16 kbyte
6ES7515-2TM01-0AB0 — I/O
ParameterValue
Input data area32 kbyte; All inputs are in the process image
Output data area32 kbyte; All outputs are in the process image
6ES7515-2TM01-0AB0 — Programming
ParameterValue
Programming language: FBDYes
Programming language: LADYes
Programming language: SCLYes
6ES7515-2TM01-0AB0 — Electrical
ParameterValue
Rated value (DC)24 V
Current consumption (rated)0.8 A
Permissible range, lower limit (DC)19.2 V
Permissible range, upper limit (DC)28.8 V
Power loss (typ.)6.3 W
6ES7515-2TM01-0AB0 — Environmental
ParameterValue
Installation altitude, max.5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Temperature, min.-40 °C
Temperature, max.70 °C
Operating temperature, min. (horizontal mounting)0 °C
Operating temperature, max. (horizontal mounting)60 °C; Display: 50 °C, at an operating temperature of typically 50 °C, the display is switched off
6ES7515-2TM01-0AB0 — Mechanical
ParameterValue
Width70 mm
Height147 mm
Depth129 mm
Weight (approx.)830 g

Product details

What ships in the box?

The 6ES7515-2TM01-0AB0 CPU with integrated PROFINET ships as a single unit ready for DIN-rail mounting. Supports DCP and DNS out of the box for network configuration.

The process image handles 32 kbyte of inputs and 32 kbyte of outputs — enough for a medium-sized line with several distributed I/O stations. Programming languages include LAD, FBD, SCL, STL, and GRAPH, covering both ladder-logic traditionalists and structured-text advocates. Integrated PID controllers for temperature and valve positioning eliminate the need for a separate loop controller for many applications. MODBUS TCP is supported natively, so integration with third-party devices like VFDs or remote I/O is straightforward.

Physical fit & environment

Dimensions are 70 mm wide, 147 mm high, and 129 mm deep — standard CPU footprint, no surprise for panel layout. Error and maintenance LEDs are present, giving quick visual status on PROFINET connection health and CPU state.

Frequently asked questions

Does the 6ES7515-2TM01-0AB0 support DCP?

Yes, DCP (Discovery and Configuration Protocol) is supported, enabling automatic device naming and IP assignment in a PROFINET network.

Does the 6ES7515-2TM01-0AB0 support DNS?

Yes, DNS (Domain Name System) is supported, allowing symbolic host-name resolution instead of hard-coded IP addresses.
