Siemens 6ES7515-2UN03-0AB0 — PLCs (Programmable Logic Controllers)

Siemens 6ES7515-2UN03-0AB0 CPU 1515-2 PN, -40-70°C, fail-saf

MPN6ES7515-2UN03-0AB0
Active

Siemens S7-1500 CPU 1515-2 PN, order code 6ES7515-2UN03-0AB0, fail-safe capable PROFINET controller with MRP, -40 to 70 °C, 32 kbyte I/O process image.

Siemens 6ES7515-2UN03-0AB0 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

6ES7515-2UN03-0AB0 — Processor & Memory
ParameterValue
Execution time, bit operations (typ.)6 ns
Execution time, word operations (typ.)7 ns
Execution time, floating-point arithmetic (typ.)37 ns
Size, max.16 kbyte
6ES7515-2UN03-0AB0 — I/O
ParameterValue
Input data area32 kbyte; All inputs are in the process image
Output data area32 kbyte; All outputs are in the process image
6ES7515-2UN03-0AB0 — Programming
ParameterValue
Programming language: FBDYes; incl. failsafe
Programming language: LADYes; incl. failsafe
Programming language: SCLYes
6ES7515-2UN03-0AB0 — Electrical
ParameterValue
Rated value (DC)24 V
Current consumption (rated)0.83 A
Permissible range, lower limit (DC)19.2 V
Permissible range, upper limit (DC)28.8 V
Power loss (typ.)7.9 W
6ES7515-2UN03-0AB0 — Environmental
ParameterValue
Installation altitude, max.5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Temperature, min.-40 °C
Temperature, max.70 °C
Operating temperature, min. (horizontal mounting)-30 °C; No condensation
Operating temperature, max. (horizontal mounting)60 °C; Display: 50 °C, at an operating temperature of typically 50 °C, the display is switched off
6ES7515-2UN03-0AB0 — Mechanical
ParameterValue
Width70 mm
Height147 mm
Depth129 mm
Weight (approx.)456 g

Product details

Controller backbone for high-speed lines

The 6ES7515-2UN03-0AB0 is a fail-safe capable PROFINET CPU with 32 kbyte each of input and output process image.

Network resilience that matters

PROFINET runs at full 100 Mbps with MRP Automanager support (IEC 62439-2 Edition 2.0), so if a switch or cable fails mid-shift, the CPU stays online — no production stop to ring an integrator. DCP and DNS are both enabled, which simplifies initial IP assignment and device discovery on a mixed-vendor line. The failsafe logic is programmed in FBD or LAD, both with failsafe instructions built in, and PROFIsafe is supported for safety-related I/O.

Mounting dimensions and sourcing

At 70 mm wide, 147 mm high, and 129 mm deep, the CPU fits DIN-rail mounting with hardware clock, up to 8 CPs/CMs via backplane. IRT unsupported; for isochronous motion see 6ES7515-2TN03-0AB0. Sourced to order; RFQ for BOM.

Frequently asked questions

Does the 6ES7515-2UN03-0AB0 support DCP?

Yes, DCP is listed as supported on this CPU, which allows for dynamic configuration of PROFINET device names and IP addresses.

Does the 6ES7515-2UN03-0AB0 support DNS?

Yes, DNS client is enabled, so the CPU can resolve hostnames on the plant network.

What is the ambient temperature range for this CPU?

The CPU is rated for -40 °C minimum to 70 °C maximum operating temperature, suitable for harsh industrial environments.

Does this CPU support IRT?

No, IRT is not supported on this variant. For isochronous real-time motion control, see the 6ES7515-2TN03-0AB0.

How much I/O process image does it have?

It provides 32 kbyte for inputs and 32 kbyte for outputs, all in the process image.
