The Siemens 6ES7924-0AA10-0BB0 is a terminal block with 8 channels and 2x2 terminals for potential supply, using a spring terminal with LED and a 16-pole IDC connection for cable. It mounts on 35 mm or 15 mm DIN rail, rated for 60 V and 1 A, with an infeed function built in. The plug-in connection type and single terminal level simplify wiring in a control panel — the LED gives a quick visual on potential presence at the terminal.
Siemens 6ES7924-0AA10-0BB0 Terminal Block, 8 Ch, 60 V, 1 A
MPN6ES7924-0AA10-0BB0
Siemens terminal block, 8 channels and 2x2 terminals for potential supply, spring terminal with LED, 16-pole IDC connection, rated 60 V / 1 A, DIN rail mount.
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jul 2026
Specifications
Connection & Wiring
| Parameter | Value |
|---|---|
| Electrical connection type, connecting cable | Plug-in connection |
| Conductor cross-section, stranded | 0.5 ... 2.5 mm² |
| Conductor cross-section, finely stranded (with ferrule) | 0.5 ... 1.5 mm² |
Electrical
| Parameter | Value |
|---|---|
| Rated current | 1 A |
| Rated value | 60 V |
Mechanical
| Parameter | Value |
|---|---|
| Mounting type | DIN rail 35 mm, DIN rail 15 mm |
| Terminal position | Top |
Environmental
| Parameter | Value |
|---|---|
| Operating temperature range | 0 ... 60 °C |
Approvals
| Parameter | Value |
|---|---|
| Ex e (EEx e) protection type tested | No |
Product details
Frequently asked questions
What are the key electrical ratings?
Rated voltage is 60 V and rated current is 1 A. The terminal block is not a disconnector and has no PE connection or shield connection.
What wire sizes does it accept?
Stranded wire: 0.5 to 2.5 mm². Finely stranded with core end processing: 0.5 to 1.5 mm². Finely stranded without core end processing: 0.5 to 2.5 mm².
How is it mounted?
Mounts on 35 mm or 15 mm DIN rail. The enclosure is black, 63 mm long, 55 mm wide, and 43.2 mm high with lowest-profile installation.
MPN
6ES7924-0AA10-0BB0
